Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
24
CONFIGURING the SERVER
UCSC-RAID-11-C240 Cisco UCSC RAID SAS 2008M-8i Mezzanine Card (RAID 0, 1, 5, 10, and 50
supported), operating at 6 Gbs.
■ Supports up to 8 internal SAS+SATA drives with the 16-drive system or up
to 16 internal SAS+SATA drives with the 24-drive system. SAS and SATA
drives can be mixed.
■ Factory-configured RAID options available: RAID 0, 1, 5, and 10 (see the
RAID PIDs section in this table)
UCSC-RAID-MZ-240 Cisco UCSC RAID SAS 2008M-8i Mezzanine Card (RAID 0, 1, 10 supported),
operating at 6 Gbs.
■ Supports up to 8 internal SAS+SATA drives with the 16-drive system or up
to 16 SAS+SATA internal drives with the 24-drive system. SAS and SATA
drives can be mixed.
■ Factory-configured RAID options available: RAID 0, 1, and 10 (see the RAID
PIDs section in this table)
Table 8 Available PCIe RAID Controller Options
Product ID (PID) PID Description
RAID Controllers
1
Note that for the UCSC-240-M3S (24-drive backplane systems), PCIe RAID controllers are installed by
default in slot 3 for 1-CPU systems and slot 4 for 2-CPU systems, and for the UCSC-C240-M3S2
(16-drive backplane systems), the controllers are installed by default in slot 3 for 1-CPU systems and
in slots 4 and 3 for 2-CPU systems.
UCS-RAID9271-8I or
UCS-RAID9271CV-8I
LSI MegaRAID SAS 9271-8i or 9271CV-8i RAID controller card with data cache
backup (RAID 0, 1, 5, 6, 10, 50, and 60), operating at 6 Gbs.
■ The UCSC-C240-M3S2 server has the following features:
• 16 disk drive backplane
• Backplane does not include a SAS expander, and can support 8 or 16
HDDs
• Single RAID controller is required to support 8 HDDs
• Need to configure two RAID controllers to suppport all 16 HDDs
■ The UCSC-C240-M3S server has the following features:
• 24 disk drive backplane
• Backplane includes a SAS expander, and can support all 24 HDDs
• Single Raid controller is required to support all 24 HDDs
■ The 9271CV-8i RAID controller card includes a 1 GB Transportable Memory
Module (TMM) and a chassis-mounted (remote) supercapacitor
(supercapacitor not available on the 9271-8i) for data cache power backup
■ Factory-configured RAID options available: RAID 0, 1, 5, 6, and 10 (see the
RAID PIDs section in this table)
■ SAS and SATA drives can be mixed
Table 7 Available Mezzanine Card RAID Options (continued)
Product ID (PID) PID Description

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
