Cisco Unified IP Phone 8941 User Manual

Related Topics
Cisco IP Phone Web Page, on page 150
Model Information Fields
The Model Information screen includes the options described in the table below.
Table 18: Model Information Settings for the Cisco Unified IP Phone 8941 and 8945
To changeDescriptionOption
Display only—cannot configure.
Model number of the phone.Model Number
Display only—cannot configure.
IP address of the phone.IP Address
Display only—cannot configure.
Host name of the phone.Host Name
Display only—cannot configure.
Version of firmware currently installed
on the phone.
Active Load
Display only—cannot configure.
Date of the most recent firmware
upgrade.
Last Upgrade
Display only—cannot configure.
IP address or name of the server to
which the phone is registered.
Active Server
Display only—cannot configure.
IP address or name of the standby
server.
Stand-by Server
Display Status Menu
The Status menu includes the following options, which provide information about the phone and phone
operations:
•
Status Messages: Displays the Status Messages screen, which shows a log of important system messages.
•
Ethernet Statistic: Displays the Ethernet Statistics screen, which shows Ethernet traffic statistics.
•
Call Statistics: Displays counters and statistics for the current call.
To display the Status menu, perform these steps:
Procedure
Step 1
To display the Status menu, press Applications.
Step 2
Select Administrator Settings > Status.
Step 3
To exit the Status menu, press Exit.
Cisco Unified IP Phone 8941 and 8945 Administration Guide for Cisco Unified Communications Manager 10.0
(SCCP and SIP)
140
Cisco Unified IP Phone Status
