Table 2: Network Port Connector Pinouts

FunctionPin Number

BI_DA+1

BI_DA-2

BI_DB+3

BI_DC+4

BI_DC-5

BI_DB-6

BI_DD+7

BI_DD-8

BI stands for bidirectional, while DA, DB, DC, and DD stand for Data A, Data B, Data C, and Data

D respectively.

Note

Computer Port Connector

The following table describes the computer port connector pinouts.

Table 3: Computer (Access) Port Connector Pinouts

FunctionPin Number

BI_DB+1

BI_DB-2

BI_DA+3

BI_DD+4

BI_DD-5

BI_DA-6

BI_DC+7

BI_DC-8

BI stands for bidirectional, while DA, DB, DC, and DD stand for Data A, Data B, Data C, and Data

D respectively.

Note
