DescriptionColourLED
Off: Monitor is not active.
Red: The system has detected a
critical overcurrent event and may
shut down.
Yellow: One or more temperature
sensors in the system are outside
the acceptable range.
Green: All the temperature sensors
in the system are within acceptable
range.
Green/Yellow/RedTEMP
Off: Fans are not being monitored.
Yellow: One or more fans in the
system are not functioning.
Green: All the fans are operational.
Yellow/Green/OffFAN
Green blinking: Blink frequency
indicates port speed:
• 1 blink+ pause - FE or GE
port operating at 10 Mb/s
• 2 blinks + pause - FE or GE
port operating at100 Mb/s
• 3 blinks + pause - GE port
operating at1000 Mb/s
Off: No link or a non-Ethernet
802.3af/t capable device is plugged
in.
Green blinking/OffEthernet SPD. (Speed of the
ethernet port)
Green: Ethernet cable is present,
and link is established with other
side
Off: No link is found
Green/OffEthernet LNK (Link State of the
ethernet port)
Green: There is at least one active
call on the onboard analog
FXS/FXO module.
Off: There is no active call on the
onboard analog FXS/FXO module.
Green/OffFXS/FXO
(Voice Port Status)
