Cisco WAP150 User Manual

• Default Gateway — The default gateway of the WAP device.
• Domain Name Server-1 — The IP address of the domain name server 1 used by the WAP device.
• Domain Name Server-2 — The IP address of the domain name server 2 used by the WAP device.
• IPv6 Address — The IPv6 address of the WAP device.
• IPv6 Autoconfigured Global Addresses — The IPv6 autoconfigured global addresses.
• IPv6 Link Local Address — The IPv6 link local address of the WAP device.
• Default IPv6 Gateway — The default IPv6 gateway of the WAP device.
• IPv6-DNS-1 — The IPv6 address of the IPv6 DNS server 1 used by the WAP device.
• IPv6-DNS-2 — The IPv6 address of the IPv6 DNS server 2 used by the WAP device.
These settings apply to the LAN interface. Click Edit to change any of these settings. You will be redirected
to the LAN page.
Click Refresh to refresh the screen and show the most current information.
Click Back to return to the Dashboard page.
Note
Wireless Status
Click the Wireless circle to display the wireless radio interfaces, such as:
• Wireless Radio — The wireless radio mode is enabled or disabled for the radio interface.
• MAC Address — The MAC address associated with the radio interface.
• Mode — The 802.11 mode (a/b/g/n/ac) used by the radio interface.
• Channel — The channel used by the radio interface.
• Operational bandwidth — The operational bandwidth used by the radio interface.
Click Edit to change any of these settings. You will be redirected to the Radio page.
Click Refresh to refresh the screen and show the most current information.
Click Back to return to the Dashboard page.
Interface Status
The Interface Status table displays the following status information for each Virtual Access Point (VAP) and
on each Wireless Distribution System (WDS) interface:
• Network Interface — The wireless interface of the WAP device.
• Name (SSID) — The wireless interface name.
• Status — The administrative status (up or down) of the VAP.
• MAC Address — The MAC address of the radio interface.
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
109
Monitor
Wireless Status

Cisco WAP150 Specifications

General

VLAN support	Yes
Number of users	64 user(s)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Antenna type	Internal
Placement	Table, Wall
Cable lock slot type	Kensington
Security algorithms	HTTPS, SSID, WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	38 mm
Width	135 mm
Weight	350 g
