Page #103 background imageLoading...
Page #103 background image
To delete or modify a class map, select the Traffic Class Name from the list and click Delete or Edit. The
class map cannot be deleted if it is already attached to a policy.
Note
Step 8 Click Apply.
Configuring MAC Traffic Classes
To add and configure a MAC class map:
Step 1 Select Client QoS > Traffic Classes.
Step 2 Click to add a Traffic Class.
The maximum number of class maps is 50.
Note
Step 3 In the Traffic Class Name field, enter the name for the new class map. The name can contain from 1 to 31 alphanumeric
and special characters. Spaces are not allowed.
Step 4 Choose MAC as the type of class map from the Class Type list. The MAC class map applies to Layer 2 criteria.
Step 5 Source Address Includes a source MAC address in the match condition for the rule.
Any Any MAC address to be used as the source address.
Single Address Enter the source MAC address to compare against an Ethernet frame.
Address/Mask Enter the source MAC address mask specifying which bits in the destination MAC address to
compare against an Ethernet frame.
For each bit position in the MAC mask, a 1 indicates that the corresponding address bit is significant and a 0 indicates
that the address bit is ignored. For example, to check only the first four octets of a MAC address, a MAC mask of
ff:ff:ff:ff:00:00 is used. A MAC mask of ff:ff:ff:ff:ff:ff checks all address bits and is used to match a single MAC
address.
Step 6 Destination Address Includes a destination MAC address in the match condition for the rule.
Any Any MAC address to be used as the destination address.
Single Address Enter the destination MAC address to compare against an Ethernet frame.
Address/Mask Enter the destination MAC address mask specifying which bits in the destination MAC address
to compare against an Ethernet frame.
Step 7 Click More..., and configure the following parameters:
Protocol Compares the match criteria against the value in the header of an Ethernet frame. Choose an EtherType
keyword or enter an EtherType value to specify the match criteria:
All Traffic Allows all traffic from any protocol.
Select From List Matches the Ethertype in the datagram header with the selected protocol types: AppleTalk,
ARP, IPv4, IPv6, IPX, NetBIOS or PPPoE.
Custom Matches the Ethertype in the datagram header with a custom protocol identifier that is specified.
The value can be a four-digit hexadecimal number in the range of 0600 to FFFF.
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
93
Access Control
Configuring MAC Traffic Classes
