26
Chapter 2 Printer Operation
Setting the Media
8. Push the head close knob to lower and lock the head unit.
Be sure to always push the head close knob to lock the head
unit. Align it with the width of the media that has been set,
then set the media width and media thickness adjustment
dials. See “Chapter 3 Printer Adjustments”.
Head close knob
Media width adjustment
Media thickness adjustment
Head unit
9. With the power switched on, push the FEED key to feed the
media. It will halt at the next print start position.
Media Thickness Adjustment
(p.50)
Media Width Adjustment (p.51)
