2
Printer Operation
20
1 PAUSE key: Temporarily pauses printing
• When this key is pushed once, the PRINT LED turns off and the printer
temporarily pauses.
• When it is pushed during printing, the printer pauses after the label
currently being printed is issued. Pressing the key a second time restarts
printing and the remaining number of designated labels are printed.
2 FEED key: Feeds media
• Pressing this key feeds media to the print start position. The distance
it is fed is determined by automatically detecting the front end of the
media when using label media, and when continuous media has been
designated, a fixed quantity is fed, then feeding stops.
• When the TEAR OFF setting is effective, feeding stops when the media
has been fed to the TEAR OFF location.
• When the optional cutter unit is installed, the media is fed to the cut
position then it is cut.
Regardless of whether there is or is not a cut operation setting on the
setting menu, if the unit is installed, the media is cut each time it is fed.
• If the optional peeler unit is installed, the media is fed to the peeling
location. When the media is pausing at the peeling position, feeding
does not occur, even if the FEED key is pushed.
3 STOP key: It stops printing and cancels the alarm
Pushing this key once during printing puts the printer in pause mode
after the label is issued. It is possible to cancel 1 batch of label issuing
data by pressing the STOP key for 4 seconds or longer in pause status.
(The PRINT LED flashes at high speed during cancel.)
4 MODE/REPEAT key:
Pressing this key reprints the last label in PRINT status (when the PRINT
LED is lit) The last label issued depends on the selection of the”MODE/
REPEAT key” menu.
Normal Operating Mode
When the power is turned on, the printer enters normal operating mode.
The control keys activate the following functions.
1
2
4
3
Menu Setup Mode (p.31)
To Next Page
