3
❚❚❚ Main Features ❚❚❚
<High-speed, high-quality printing>
This printer can be used for high-speed high-quality printing thanks to its direct thermal method
and thermal transfer method that use a line thermal printhead together with its 32 bit RISC CPU
and its 'history control IC'.
<Easy operation>
It is easy to change the printer’s settings on the operation panel, thanks to its unique and
simple VuePrint menu system.
Its high-lift printhead and mechanism means that media and ribbon can be loaded with ease
and it is constructed for easy thermal printhead cleaning, etc.
Media width adjustment, media thickness adjustment, and media sensor adjustment can all be
made easily by the user using the colour-coded operator controls.
<Interface>
A serial port, IEEE1284 parallel port (ECP mode) and USB are standard equipment, for quick data
transfer and printing.
<Optional interface>
The printers have optional internally housed network interfaces.
<Optional auto-cutter / peeler unit>
The auto-cutter and peeler units are designed so that they can be installed easily.
<Adjustable sensors>
The adjustable media sensors - which allow the sensors to be positioned in different locations
across the media - are standard features making the printer ideal for use with special media.
<Installation>
The interface, power switch etc. are installed towards the back and the top cover opens and
closes vertically so that the sides of the printer are not restricted.
INTRODUCTION
Thank you for purchasing a Citizen CLP label printer offering high performance printing at up to 4 inches per
second on media up to 4.1 inches wide.

Other manuals for Citizen CLP-621

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Citizen CLP-621 and is the answer not in the manual?

Citizen CLP-621 Specifications

General IconGeneral
USB portNo
RS-232 interfaceYes
Optional connectivityEthernet
USB 1.1 ports quantity1
USB 2.0 ports quantity0
Connectivity technologyWired
Flash memory2 MB
CertificationUL, C-UL, FCC class A, CCC, CE Marking
Internal memory8 MB
Number of fonts2
Built-in barcodesPDF417, UPC-A, UPC-E
Built-in processor32 Bit RISC
Mean cycles between failures (MCBF)1000
Power consumption2400 mA
Power requirements100 - 240V, 50 / 60Hz
Compatible operating systemsWindows 2000, XP, Vista
Core diameter25.4 mm
Ribbon length360 m
Media thickness0.0635 - 0.254 mm
Maximum label length812 m
Maximum roll diameter127 mm
Supported paper width19.5 - 118 mm
Weight and Dimensions IconWeight and Dimensions
Depth114 mm
Width91 mm
Height104 mm
