Citizen CLP-621 User Manual

29
Printer Operation
Mode Settings
Mode Key operation
HEX dump mode Turning power on while pushing the STOP key.
Self print mode Turning power on while pushing the FEED key.
Menu setting mode Turning power on while pushing the MODE/REPEAT key.
HEX Dump Mode
 When using label media
Turn on printer power while pushing the STOP key. If the PRINT LED has
begun to flash slowly, release the STOP key, and then the printer enters
HEX DUMP mode.
 When using continuous media
Turn on printer power while pushing the STOP key. If the PRINT LED has
stopped flashing slowly and begun to flash rapidly, release the STOP key,
and then the printer enters HEX dump mode.
DUMP LIST
Turning on the power while pressing keys in the following combinations starts
various functions.
Operation Panel (P.15)
* To exit HEX Dump Mode, turn off the power to the printer then turn the power on
again (restart).

Citizen CLP-621 Specifications

General

USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Flash memory	2 MB
Certification	UL, C-UL, FCC class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Power consumption	2400 mA
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000, XP, Vista
Core diameter	25.4 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	114 mm
Width	91 mm
Height	104 mm
