Citizen CLP-621 User Manual

27
Printer Operation
4. Push the large blue-head open lever to release the head unit.
Pull out the ribbon from the bottom of the head unit to the
ribbon winding side.
5. Using tape etc., fix the ribbon that you have pulled out on the
ribbon holder on which the paper core has been set and wind it
on the ribbon holder.
Winding side
ribbon holder
Winding side
ribbon holder
3. Install the unused ribbon and holder in to the rear ribbon drive
unit. The splines on the ribbon drive gear mechanism engage
with the end of the ribbon holder.
1
2
Setting the Ribbon

Citizen CLP-621 Specifications

General

USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Flash memory	2 MB
Certification	UL, C-UL, FCC class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Power consumption	2400 mA
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000, XP, Vista
Core diameter	25.4 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	114 mm
Width	91 mm
Height	104 mm
