2-4. Connecting the Interface Board Unit
1) The interface board can be used by connecting it to the main board of a printer.
The printer interface connector is connected to the connector of the main board of the printer.
You can also replace another interface with the wireless LAN interface but care is required.
(Diagram below shows a typical example)
2) If another interface board is installed in the printer, remove
it.
• Malfunctions may occur if the interface board is removed or re-inserted.
• To install the interface board, please contact your dealer or service person.
• If you work on your own, consider static electricity and other factors carefully and then install
the interface board at your own responsibility.
Printer interface connector
To Next Page
