2 Web Manager
32
4-4-1. CONFIG>>General Tab
LAN board Information
・ LAN board name (factory default: Net Printer)
Set the ID of the Interface board.
TCP/IP
・ Obtain an IP Address Automatically (factory default)
Automatically obtain the IP address from the DHCP server.
・ Use the following IP Address
Enter IP addresses in the IP Address, Subnet Mask, and Default Gateway fields.
UPnP Setting
・ UPnP (factory default: Enable)
Set the UPnP setting.
LAN Setting
・ Priority to Ethernet (factory default: Enable)
Enable: When Ethernet cable is connected, LAN (Ethernet) is chosen.
Disable: The connection is fixed for either LAN or WLAN chosen at boot.
WLAN at boot + Ethernet connected later
LAN at boot + Ethernet disconnected later
