2 Network Settings and Operation
18
LAN Connection and DHCP Off
Title of the printout.
Model name, hardware revision, and
firmware version of the interface board.
System information of the interface board.
The LAN board name, serial number, and
MAC address are printed.
Network information of the interface board.
Information of Wi-Fi adapter and access
point that the interface board is connected.
“Module” is printed when USB Wi-Fi adapter
is in place.
Other 2 items are printed when connected
with access point. Until establishing the
connection, it is printed as “Scanning”.
Printer information. The name of the
manufacturer and the model name of the
printer connected to the interface board are
printed.
The configuration information of the
interface board. The information stored in
the interface board is printed and may be
different from the connection status of the
current network. Check the connection
status using the network information of .
I/F Board
Information
IFx-WFXx(Rev0.1.3): Ver 2.00
System
WLAN Board Name : Net Printer
Serial Number : 100123
MAC Address : 00:01:02:0a:0b:0c
Current Network Status
IP Address : 192.168.0.2 (DHCP)
Subnet Mask : 255.255.255.0
Gateway : 192.168.0.1
DHCP Server : 192.168.0.1
Ethernet Status
Speed & Duplex : Auto (100BaseTx Full)
Printer Status
Manufacturer : CITIZEN
Model : CT-S801
User Configuration
DHCP : Enable
IP Address : 192.168.0.10
Subnet Mask : 255.255.255.0
Gateway : 192.168.0.1
Print Port : 9100
Receive Timeout : 180
Wireless Type : Infrastructure
SSID : CITIZENSYSTEMS
Security : None
