128
CLUTCH
GEARBOX
TRANSMISSION
Tightening torques (m.daN)
Ref. Description Number of screws Tightening
Align the reference “b”
Screws for clutch Position the mechanism using
1
mechanism on flywheel the top screw “a”
Tightening 1,9 ± 0,1
2 Screws for flywheel 7,8 ± 0,7
B2B2017D
CLUTCH TIGHTENING TORQUES
B2B2016D
