CITROEN C1 - Aircon Circuit: 8 HT Engine

191
AIR
CONDITIONING
AIR CONDITIONING CIRCUIT R 134.a
Engine : DV4TD
(10) Low pressure valve.
(11) High pressure valve.
(12) Pressostat
“a” Pressure reducer outlet : 1 ± 0,1
“b” Pressure reducer inlet : 1 ± 0,1
“c” Condenser outlet : 1 ± 0,1
“d” Aircon compressor inlet : 1 ± 0,1
“e” Aircon compressor outlet : 1 ± 0,1
“f” Condenser inlet : 1 ± 0,1
C5H2025D
