GENERAL
GENERAL SPECIFICATION : LIFTING AND SUPPORTING THE VEHICLE
Note on use of a 4-point lift with moving arms
IMPERATIVE : Position the safety straps, if placing the vehicle on a lift supported from the jacking points
(risk of the vehicle overbalancing when a heavy component is removed).
Equip the moving arms with rubber blocks as indicated.
To use this lift, align the middle of it as far as possible with the centre of gravity of vehicle.
Present the vehicle as far as possible in the axis of the moving arms. Adjust the moving arms to the
vehicle’s jacking points.
WARNING : Do not raise the vehicle too high, to avoid all risk of instability.
Lock the moving arms while the repairs are being carried out.
Raise the vehicle just off the ground and check that it is stable.
Example :
2-column lift
Place the safety straps [1] under the lift arm and criss-crossing the vehicle
E2A200BD
Lifting and supporting the vehicle
