128
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT 2002
Engines: 6FZ - RFN
Without air conditioning. With air conditioning.
Tools.
[1]
Pliers for removing plastic pegs : 7504-T
Remove the belt.
- Detension the belt (3) by turning the screw (2) of the tensioner roller (1)
(anti-clockwise).
- The screw
(2) (WARNING: not left hand screw).
- Remove the belt (3), while keeping the tensioner roller (1) tight.
Refit the belt.
- Refit the belt (3), while keeping the tensioner roller (1) tight.
- Release the tensioner roller (1).
B1BP23PC B1BP23QC B1BP23PC B1BP23RC
XSARA - XSARA PICASSO
