129
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT 2002
Sans Power-assisted steering.
Tools.
[1] Belt tension measuring instrument : 4122-T
Removal.
- Loosen the screws (2).
- Tighten the screw
(1) until it is against its stop.
- Remove the belt.
Refitting.
- Refit the belt.
- Fit the tool [1] on the belt at "d".
- Tighten the screw (1) to obtain: 106 ± 10 SEEM units.
- Tighten the screws (2) to 2 m.daN.
- Remove the tool
[1].
B1BP1SECB1BP1SDC
Engine: WJY
XSARA
