130
ENGINE
XSARA
AUXILIARY EQUIPMENT DRIVE BELT 2002
Sans Power-assisted steering With air conditioning.
Tools.
[1]
Belt tension measuring instrument : 4122-T
Removal.
- Loosen the screws (1).
- Tighten the screw (2) until it is against its stop.
- Remove the belt.
Refitting.
- Refit the belt.
- Fit the tool [1] at "e".
- Tighten the screw (2) to obtain: 106 ± 10 SEEM units.
- Tighten the screws (1) to 2 m.daN.
- Remove the tool [1].
B1BP1SGCB1BP1SFC
Engine: WJY
