215
ENGINE
CHECKING AND SETTING THE VALVE TIMING
Engine: WJY
Setting the timing (continued).
Tighten:
- Screw (9) to 2.1 ± 0.2 m.daN.
- Screws (5) to 2,3 ± 0.2 m.daN.
- Screws (6) to 2,3 ± 0.2 m.daN.
- Remove and refit tool [7].
- The tension value should be between 38 and 46 SEEM units.
- Remove tools [7], [2], [3] and [4].
- Turn the crankshaft 2 times in the normal direction of rotation.
- Peg the flywheel, using the peg [2].
- Visually check the peggings of the camshaft and injection pump.
ESSENTIAL: Visually check that the offsets between the holes of
the camshaft and injection pump hubs and the corresponding
pegging holes are not more than 1 mm. If necessary, recommence
the procedure for fitting the timing belt.
XSARA
Setting the timing (continued).
- Remove the peg [2].
- Remove the screw (4) and the washer.
- Refit the lower cover (3).
- Refit the intermediate cover (2).
- Refit the upper cover (1).
- Remove the RH engine support.
- Take away the workshop hoist.
- Remove the plugs and recouple the diesel fuel delivery and return
hoses.
- Refit the accessories drive belt (see corresponding operation).
- Refit the RH lower splash-shield.
- Disengage 5th gear.
- Connect the battery.
