388

AXLES

SUSPENSION

STEERING

FRONT AXLEXSARA

Pivot ball-joint:

- Manual steering, groove at «b».

- Power steering, groove at

«b».

Tongue «a» towards the front.

B3CP049C

B3CP043D
