89
ENGINE
SPECIAL FEATURES - TIGHTENING TORQUES (m.daN )
CYLINDER HEAD (mm)
Engine types KFW NFV NFU
Maximum permissible bow 0,05
Gasket surface regrinding - 0,20
TIGHTENING TORQUES (m.daN)
Crankshaft bearing Pre-tightening 2 ± 0,2 2 ± 0,2
screws Angular tighten 45° 50° ± 5°
Connecting rod screws Tightening 3,8 ± 0,4
Flywheel screw Tightening 6,5 ± 0,7
Crankshaft pinion screw Pre-tightening
Angular tighten 10 ± 1
Camshaft pulley screw Pre-tightening
Angular tighten 8 ± 0,8
Camshaft hubs 8 ± 0,8
Camshaft hub screw Tightening 1 ± 0,1
XSARA - XSARA PICASSO
