CKD EVD-3000 Series User Manual

SM-A20758-A/3 1. PRODUCT OVERVIEW
8 2020-10-06
Specifications
◼ EVD-1100-C (maximum pressure: 100 kPa)
Item
EVD-1100-C [*2] [*3]- [*4] [*] -3
Working fluid
Clean compressed air (equivalent to ISO Class 1. 3. 2)
Max. working pressure
160 kPa
Min. working pressure
Control pressure +50 kPa
Proof pressure
Inlet side
240 kPa
Outlet side
150 kPa
Pressure control range
Note 1
0 kPa to 100 kPa
Power supply voltage
24 VDC ± 10% (stabilized power supply with ripple rate of 1% or less)
Current consumption
Note 2
0.15 A or less (starting current is 0.6 A or less when the power is turned on)
(Port type A)
Input signal
IO-Link
Preset input
8-point (IO-Link)
Pressure display
Display method
3-digit 7-segment LED,
display accuracy: ±2%FS or less
Display range
0 kPa to 100 kPa
Display
resolution
1 kPa
Direct memory setting
1 kPa to 100 kPa
(min. set width 1 kPa/set resolution 1 kPa)
Hysteresis
Note 3
0.5%FS or less
Linearity
Note 3
±0.3%FS or less
Resolution
Note 3
0.2%FS or less
Repeatability
Note 3
0.3%FS or less
Temperature
characteristics
Zero point
fluctuation
±0.15%FS/°C or less
Span drift
±0.07%FS/°C or less
Max. flow rate (ANR)
Note 4
60 L/min
Step response Note 5
No load
0.2 sec or less
With 1000 cm
3
load
0.8 sec or less
Vibration resistance
98 m/ s
2
or less
Ambient temperature
5°C to 50°C
Fluid temperature
5°C to 50°C
Port size [*2]
[*2] =08 Rc1/4
[*2] =08G G1/4
[*2] =08N NPT1/4
Unit change [*3]
Note 6
None
Without Unit change function
KA
Unit change kPa / psi / bar (Accessory ： Unit label sticker psi / bar)
Mounting orientation
No restriction
Weight (body)
250 g
Protection circuit
Power reverse connection protection
Note 1: There is 1%FS or less residual pressure (1 kPa or less) when the input signal is 0%.
Note 2: Use the power supply unit that have the power supply ability sufficiently to each port of IO-Link master.
Note 3: The above characteristics are based on the condition that power supply voltage is 24 VDC ± 0.1 VDC, working pressure
is set to maximum control pressure +50 kPa, and control pressure is 10% to 90% (with no load, ambient temperature of
25°C ± 3°C).
Also, the specified values are only for when the secondary side is a closed circuit and pressure fluctuations will occur if
the product is used for blowing or similar applications.
Note 4: The above characteristics are based on the condition that working pressure and control pressure are set to their maximum.
Note 5: The above characteristics are based on the condition that working pressure is set to maximum and the step amount is
changed from 50%F.S.→100%F.S.
50%F.S.→60%F.S.
50%F.S.→40%F.S.
Note 6: KA type is only available outside Japan.
