1. PRODUCT OVERVIEW
Part Name
Body
◼ EVD-1000 Series
LED display
Operation keys
Threaded hole for mounting the bracket
Port R
(pilot air exhaust)
Exhaust port
(main air exhaust)
*Please attach the unit label sticker
according to the unit to be used.
Unit label sticker
(Accessory)
Option KA type only
M12,4pin connector
