CKD SHD3025 - Internal Structure Drawing

<SM-13024-A>
20
8-3Internalstructuredrawing
No. Partsname No. Partsname
1 PanheadBtightscrew 36 Mainblockplate
2 Tappingtrussheadscrew3 37 Outletpiping
3 SidepanelL 38 Exhaustblock 
4 Operationpanelassembly 39 Exhaustvalveassy
5 Tappingtrussheadscrew1 40 Hexagonsocketheadcapbolt
6 Frontpanel 45 Exhaustpipingadapter
7 Rubberbushing 46 Nut
8 Base 47 Silencertopplate
9 Shieldplate 48 Silenceroutermedia
10 PanheadBtightscrew 49 Silencermediummedia
11 SidepanelR 50 Silencerinnermedia
12 Tappingtrussheadscrew3 51 Silencerbottomplateassembly
13 Base 52 Tierod
14 Pinwelded 53 Rearpanel
15 Hexagonnut 54 Pipeguide
16 Microalescer  
17 Dewpointsensor  
18 Unitbaseassembly  
19 Mainpanel  
20 Tappingtrussheadscrew3  
21 Inletvalveassembly  
22 Checkvalveassembly  
23 Orifice  
24 Mainblock  
25 Outletpiping  
26 Pipingadapter  
27 Oring  
28 Oring  
29 Passagegasket  
30 PassageR  
31 Bodyclamp  
32 Oring  
33 Desiccantvesselassembly  
34 Passagecap  
35 PassageL  
