CKD SHD3025 - Operation Output

<SM-13024-A>
11
5-7Operationoutput
1) Non-voltagecontactoutput closedduring operationisequippedstandardly.Wireproper basedon
｢8-5Electriccircuitdiagram｣.
2)
Keep in mind that the contact capacity of the relay for an output and the minimum
applicationloadareshowninthe 「8-5electriccircuitdiagram」.
5-8 Parametersettingchange
1) When you change a setupof a control board unavoidably,Changecarefully in the
followingprocedures.
① StopthismachinewiththeSTOPbutton.
② PushingtheSTOPbuttonpreviously,pushtheECOMODEbuttonfor5seconds. 
③ Adisplaypartissetto           and    blinks.
④ Themeaningofadisplaynumberisshownbelow.
ＮＯ Display
number
Contents
１    Thedewpointexcludeden
ergysavingatthetimeof 
10℃ setup
Over-12℃
２ Thedewpointincludedinenergysavingatthetime
of
10℃ setup
Lessthan
-14℃
３ Thedewpointexcludedenergysavingatthetimeof
20℃ setup
Over-22℃
４ Thedewpointincludedinenergysavingatthetime
of
20℃ setup
Lessthan
-24℃
５   
Thedewpointexcluded
energysavingatthetimeof 
40℃ setup
Over-42℃
６   
Thedewpointincludedinenergysavingatthetime
of
40℃ setup
Lessthan
-44℃
７   
Thedewpointexcludedenergysavingatthetimeof
60℃ setup
Over-62℃
８   
Thedewpointincludedinenergysavingatthetime
of
60℃ setup
Lessthan
-64℃
９   
Factoryset
(Donttouch)
１０
.
１１
.
１２
.
１３
.
Display part
