4
1.
Crop
divider
2.
Reel
3.
Cutterbar
auger
4.
Feeder
chains
5.
Stone
trap
6.
APS concave
7.
APS drum
8.
Main drum
9.
Impeller
10.
Straw walker
11.
Intensive separator system
12.
Preparation floor
13.
Fan
14.
Top sieve
15.
Bottom sieve
16.
Clean grain auger
17.
Returns auger
18.
Unloading auger
19.
Straw chopper
20.
Engine
