Clarion NX604 User Manual

28 NX604/FX503
English
<Connection example> When using AUX2
✽
The illustrations for the main unit are of the NX604.
Commercially available
portable device
VTR
cable
Video jack
Audio jack
VIDEO IN
AUDIO IN
MEMO:
s!LSOREFERTOTHE5SERS-ANUALFORTHE
CONNECTEDEXTERNALDEVICE
s%XTERNALINPUTCONNECTORJACK
- !MMDIASTEREOMINIPLUGCAN
BECONNECTED4HOROUGHLYREADTHE
5SERS-ANUALFORTHEAUDIOCABLE
WITHOUTRESISTORANDTHEDEVICETOBE
CONNECTED
- 5SETHEBATTERYETCPROVIDEDWITHTHE
DEVICEASTHEPOWERSUPPLYFORTHAT
DEVICE5SINGANEXTERNALDEVICEWHILE
ITISBEINGCHARGEDBYTHEACCESSORY
SOCKETONTHEVEHICLESOMETIMESCAUSES
NOISE
s4HESCREENMOMENTARILYTURNSBLACKWHEN
SWITCHINGBETWEENTHEAUDIOANDVIDEO
MODES(OWEVERTHISISNOTAMALFUNCTION
Listening to BVEJP from
external devices
1
MENU AUX1
or
AUX2
2
Touch the screen
Audio
3
Operate the external device.
Audio is played.
Viewing connected
external devices (AUX)
Audio and video from external devices
connected to the AUX terminal can be
played on the unit by switching the audio
mode to AUX1 or AUX2.
WARNING
s For your safety, the driver should
not watch the video or operate the
controls while driving. Please note
that watching and operating the
video while driving are prohibited by
law in some countries.
Preparations
●
The following cables are required for
connecting external devices to the unit.
(When using AUX1)
To listen to audio
sCommercially available 3.5 mm stereo
mini plug cable
To watch video
sSpecialized front VTR input cable
(CCA-772), sold separately
✽
Any cable other than the one noted
above may not operate normally.
(When using AUX2)
sVTR cable
Attention
s$ONOTLEAVECONNECTEDEXTERNALDEVICES
INSIDETHEVEHICLE4HEINSIDEOFTHE
VEHICLEGETSHOTUNDERTHEBLAZINGSUN
FOREXAMPLEANDMIGHTCAUSETHEMTO
MALFUNCTION
Notice
s&ORYOURSAFETYTHISSYSTEMHASASAFETY
FUNCTIONWHICHTURNSOFFTHEPICTUREWHEN
THECARISMOVINGSOONLYTHEAUDIO
CANBEHEARD4HEPICTURECANONLYBE
WATCHEDWHENTHECARISSTOPPEDANDTHE
PARKINGBRAKEISAPPLIED
Connecting external devices
<Connection example> When using AUX1
✽
The illustrations for the main unit are of the NX604.
Commercially available
portable device
(Example: For audio)
3.5 mm AV mini plug cable
(commercially available product)
