Clarion NX700 Service Manual

NX700/NX700E
- 31 -
L138 010-3105-62 1k ohm/100MHz
L139 010-3105-62 1k ohm/100MHz
L140 010-3105-62 1k ohm/100MHz
L141 010-3105-69 80 ohm/100MHz
L142 010-3105-69 80 ohm/100MHz
L143 010-3105-69 80 ohm/100MHz
L701 010-3059-90 200 ohm FILTER
L702 010-3108-54 600 ohm/100MHz
L703 010-3108-54 600 ohm/100MHz
P701 076-0529-02 2P
Q100 125-7011-90 RSR025P03TL
Q102 125-7011-90 RSR025P03TL
Q103 125-7011-90 RSR025P03TL
Q104 125-3014-90 ISA1602AM1 E,F
Q105 125-3014-90 ISA1602AM1 E,F
Q106 125-8028-90 RSR025N03 TL
Q107 125-7011-90 RSR025P03TL
Q108 125-0034-93 RT1P241M
Q109 125-2041-93 RT1N241M
Q110 125-2041-93 RT1N241M
Q112 125-2041-93 RT1N241M
Q113 125-0034-93 RT1P241M
Q701 125-0025-92 RN2302
Q702 125-2032-92 RN1302
Q705 192-4155-49 2SC4155A R,S
Q901 192-4081-00 2SC4081
Q902 192-4081-00 2SC4081
R101 119-1301-15 1/10W 13 ohm
R102 032-0217-56 1/3W 0.047 ohm
R103 119-1031-15 1/10W 10k ohm
R105 032-0140-12 1/10W 75 ohm F
R106 119-1301-15 1/10W 13 ohm
R108 119-6201-15 1/10W 62 ohm
R109 119-1301-15 1/10W 13 ohm
R110 032-0217-56 1/3W 0.047 ohm
R111 032-0140-12 1/10W 75 ohm F
R114 119-6201-15 1/10W 62 ohm
R115 119-1301-15 1/10W 13 ohm
R116 032-0140-12 1/10W 75 ohm F
R117 119-6201-15 1/10W 62 ohm
R118 119-6201-15 1/10W 62 ohm
R119 032-0219-50 1/8W 0.22 ohm
R120 119-6201-15 1/10W 62 ohm
R121 032-0140-12 1/10W 75 ohm F
R123 119-6201-15 1/10W 62 ohm
R124 032-0140-04 1/10W 8.2k ohm F
R125 032-0140-50 1/10W 10k ohm F
R126 032-0140-99 1/10W 39k ohm F
R127 032-0140-55 1/10W 4.7k ohm F
R128 119-0000-05 1/10W 0 ohm JW
R131 119-3311-15 1/10W 330 ohm
R132 119-1021-15 1/10W 1k ohm
R133 119-4791-15 1/10W 4.7 ohm
R136 119-4721-15 1/10W 4.7k ohm
R137 119-3301-15 1/10W 33 ohm
R139 119-1041-15 1/10W 100k ohm
R140 119-1051-15 1/10W 1M ohm
R141 119-1001-15 1/10W 10 ohm
R144 119-0000-05 1/10W 0 ohm JW
R145 119-1031-15 1/10W 10k ohm
R146 119-2221-15 1/10W 2.2k ohm
R147 119-2221-15 1/10W 2.2k ohm
R149 119-3331-15 1/10W 33k ohm
R150 119-3331-15 1/10W 33k ohm
R151 119-1031-15 1/10W 10k ohm
R152 119-1031-15 1/10W 10k ohm
R153 119-3331-15 1/10W 33k ohm
R154 119-3321-15 1/10W 3.3k ohm
R155 119-3331-15 1/10W 33k ohm
R157 032-0140-04 1/10W 8.2k ohm F
R158 119-1031-15 1/10W 10k ohm
R159 119-2231-15 1/10W 22k ohm
R160 032-0140-52 1/10W 33k ohm F
R161 119-1031-15 1/10W 10k ohm
R163 032-0217-56 1/3W 0.047 ohm
R165 119-0000-05 1/10W 0 ohm JW
R166 119-0000-05 1/10W 0 ohm JW
R168 032-0219-50 1/8W 0.22 ohm
R169 032-0140-94 1/10W 30k ohm F
R170 119-0000-05 1/10W 0 ohm JW
R171 119-0000-05 1/10W 0 ohm JW
R172 119-0000-05 1/10W 0 ohm JW
R173 032-0140-08 1/10W 13k ohm F
R177 032-0140-50 1/10W 10k ohm F
R178 119-3301-15 1/10W 33 ohm
R179 119-3301-15 1/10W 33 ohm
R180 119-3301-15 1/10W 33 ohm
R181 119-1211-15 1/10W 120 ohm
R182 119-0000-05 1/10W 0 ohm JW
R183 119-0000-05 1/10W 0 ohm JW
R185 119-0000-05 1/10W 0 ohm JW
R188 119-0000-05 1/10W 0 ohm JW
R194 116-5611-15 1/4W 560 ohm
R197 119-4731-15 1/10W 47k ohm
R198 119-4731-15 1/10W 47k ohm
R199 119-0000-05 1/10W 0 ohm JW
R200 119-0000-05 1/10W 0 ohm JW
R201 119-4731-15 1/10W 47k ohm
R202 119-0000-05 1/10W 0 ohm JW
R203 119-6891-15 1/10W 6.8 ohm
R204 119-6891-15 1/10W 6.8 ohm
R205 119-6891-15 1/10W 6.8 ohm
R206 119-6891-15 1/10W 6.8 ohm
R208 119-0000-05 1/10W 0 ohm JW
R213 119-0000-05 1/10W 0 ohm JW
R215 119-4721-15 1/10W 4.7k ohm
R216 119-4731-15 1/10W 47k ohm
R217 119-4721-15 1/10W 4.7k ohm
R218 119-4731-15 1/10W 47k ohm
R221 119-0000-05 1/10W 0 ohm JW
R250 119-4731-15 1/10W 47k ohm
R252 119-2211-15 1/10W 220 ohm
R253 119-1511-15 1/10W 150 ohm
R254 119-1511-15 1/10W 150 ohm
R255 119-1511-15 1/10W 150 ohm
R260 119-1041-15 1/10W 100k ohm
R261 119-1041-15 1/10W 100k ohm
R262 119-4731-15 1/10W 47k ohm
R263 119-4731-15 1/10W 47k ohm
R264 119-4731-15 1/10W 47k ohm
R701 116-6811-15 1/4W 680 ohm
R702 119-1041-15 1/10W 100k ohm
R703 119-3931-15 1/10W 39k ohm
R705 032-0140-05 1/10W 82k ohm F
R706 119-3351-15 1/10W 3.3M ohm
R707 119-1021-15 1/10W 1k ohm
R708 119-1021-15 1/10W 1k ohm
R709 119-1031-15 1/10W 10k ohm
R711 119-6841-15 1/10W 680k ohm
R712 119-1051-15 1/10W 1M ohm
R713 032-0140-79 1/10W 2.7k ohm F
R714 032-0140-90 1/10W 560 ohm F
R715 119-1021-15 1/10W 1k ohm
R716 119-1021-15 1/10W 1k ohm
R720 119-1021-15 1/10W 1k ohm
R721 119-1021-15 1/10W 1k ohm
R901 119-1021-15 1/10W 1k ohm
R902 119-1011-15 1/10W 100 ohm
R903 119-3311-15 1/10W 330 ohm
R904 119-3311-15 1/10W 330 ohm
R905 119-3311-15 1/10W 330 ohm
R906 119-2211-15 1/10W 220 ohm
R907 119-5611-15 1/10W 560 ohm
S901 013-6312-50 SKRP-ABE-010
S902 013-6318-51 SKRKAEE010
S903 013-6318-51 SKRKAEE010
S904 013-6318-51 SKRKAEE010
T701 007-1178-00 OUTPUT-TRANS
BLC4126
TM100 073-0762-90 TERMINAL
TM101 073-0762-90 TERMINAL
TM102 073-0762-90 TERMINAL
TM103 073-0762-90 TERMINAL
TM104 073-0785-90 TERMINAL
TM105 073-0785-90 TERMINAL
X101 061-3569-90 NX3225GA
PWB 039-3500-00 PWB(WITHOUT
COMPONENTS)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
