Clarion NX700 Service Manual

NX700/NX700E
- 32 -
Main PWB(B2) section
ANT201 092-2216-50 ANTENNA RECEPT
ANT202 092-2203-00 ANT-RECEPT
(NX700E)
C101 168-1022-55 1000pF K
C102 166-2096-50 2pF +/-0.25pF CK
C104 166-1501-50 15pF CH
C105 168-1022-55 1000pF K
C106 166-3901-50 39pF CH
C107 168-2242-58 0.22uF K
C108 166-1201-50 12pF CH
C109 168-2242-58 0.22uF K
C110 168-1052-78 16V 1uF K
C111 168-2242-58 0.22uF K
C112 166-1201-50 12pF CH
C113 168-1052-78 16V 1uF K
C114 168-1032-55 0.01uF K
C115 168-1032-55 0.01uF K
C116 168-1032-55 0.01uF K
C117 168-1042-78 16V 0.1uF K
C118 168-1042-78 16V 0.1uF K
C119 168-1032-55 0.01uF K
C120 168-2232-55 0.022uF K
C121 177-1062-78 10pF
C122 168-1042-78 16V 0.1uF K
C123 168-1042-78 16V 0.1uF K
C124 043-6401-90 16V 10uF
(NX700E)
C200 166-2201-50 22pF CH
C202 168-1042-78 16V 0.1uF K
C203 043-0540-00 6.3V 10uF
C204 043-0540-00 6.3V 10uF
C205 166-2211-50 220pF CH
C206 166-2211-50 220pF CH
C207 043-0540-00 6.3V 10uF
C208 043-0540-00 6.3V 10uF
C209 043-0540-00 6.3V 10uF
C210 043-0540-00 6.3V 10uF
C211 168-1042-78 16V 0.1uF K
C213 168-1052-78 16V 1uF K
(NX700)
C214 168-1052-78 16V 1uF K
(NX700)
C215 168-1052-78 16V 1uF K
(NX700)
C216 168-1052-78 16V 1uF K
(NX700)
C217 168-1052-78 16V 1uF K
C218 043-0540-00 6.3V 10uF
C219 168-1052-78 16V 1uF K
C220 168-1052-78 16V 1uF K
C221 168-1052-78 16V 1uF K
C227 166-1211-50 120pF CH
C228 166-1211-50 120pF CH
C229 166-5611-50 560pF CH
C230 166-5611-50 560pF CH
C231 166-5611-50 560pF CH
C232 166-5611-50 560pF CH
C233 166-5611-50 560pF CH
C234 166-2201-50 22pF CH
C235 166-5611-50 560pF CH
C236 166-2201-50 22pF CH
C237 166-5611-50 560pF CH
C238 166-5611-50 560pF CH
C243 168-1042-78 16V 0.1uF K
C245 042-1764-90 16V 100uF M
C246 168-1042-78 16V 0.1uF K
C247 166-2096-50 2pF +/-0.25pF CK
(NX700)
C248 166-3901-50 39pF CH
(NX700E)
C249 166-2096-50 2pF+/-0.25pF CK
(NX700E)
C250 166-3901-50 39pF CH
(NX700E)
C251 168-1052-78 16V 1uF K
C252 168-1052-78 16V 1uF K
C253 165-4763-35 16V 47uF
(NX700E)
C256 168-1042-78 16V 0.1uF K
C257 168-1042-78 16V 0.1uF K
C258 165-4763-35 16V 47uF
C259 168-1042-78 16V 0.1uF K
(NX700E)
C260 168-1042-78 16V 0.1uF K
C261 166-5611-50 560pF CH
(NX700E)
C262 168-1042-78 16V 0.1uF K
C263 165-4763-35 16V 47uF
C264 166-3311-50 330pF CH
(NX700E)
C265 166-2201-50 22pF CH
(NX700E)
C268 165-1063-35 16V 10uF
(NX700E)
C269 166-3301-50 33pF CH
(NX700E)
C271 166-2201-50 22pF CH
(NX700E)
C272 168-1022-55 1000pF K
C273 168-1022-55 1000pF K
C274 168-1022-55 1000pF K
C275 168-1042-78 16V 0.1uF K
C279 166-2201-50 22pF CH
C280 166-2201-50 22pF CH
C282 168-1042-78 16V 0.1uF K
C283 168-1042-78 16V 0.1uF K
C284 168-1042-78 16V 0.1uF K
C285 168-1042-78 16V 0.1uF K
C287 168-1052-78 16V 1uF K
C288 165-1063-35 16V 10uF
C292 168-1042-78 16V 0.1uF K
(NX700E)
C293 168-1042-78 16V 0.1uF K
C294 165-1063-35 16V 10uF
C295 165-1063-35 16V 10uF
C296 165-1063-35 16V 10uF
C297 165-1063-35 16V 10uF
C298 165-1063-35 16V 10uF
C299 165-1063-35 16V 10uF
C300 165-1063-35 16V 10uF
C301 165-1063-35 16V 10uF
C302 166-3911-50 390pF CH
C303 166-3911-50 390pF CH
C304 043-0540-00 6.3V 10uF
C305 043-0540-00 6.3V 10uF
C322 168-1022-55 1000pF K
C323 168-1022-55 1000pF K
C324 168-2242-58 0.22uF K
C325 168-2242-58 0.22uF K
C326 168-2242-58 0.22uF K
C327 168-2242-58 0.22uF K
C385 166-1011-50 100pF CH
C386 166-1011-50 100pF CH
C387 168-1042-78 16V 0.1uF K
C388 168-1032-55 0.01uF K
C401 043-0540-00 6.3V 10uF
C404 043-0540-00 6.3V 10uF
C405 043-0540-00 6.3V 10uF
C406 168-1042-78 16V 0.1uF K
C407 043-6401-90 16V 10uF
C408 166-1007-50 10pF CH
C410 168-1022-55 1000pF K
C423 168-1042-78 16V 0.1uF K
C424 168-1042-78 16V 0.1uF K
C425 168-1042-78 16V 0.1uF K
C426 168-1042-78 16V 0.1uF K
C427 042-1764-90 16V 100uF M
C428 168-1042-78 16V 0.1uF K
C429 168-1052-78 16V 1uF K
C430 168-1052-78 16V 1uF K
C431 168-1042-78 16V 0.1uF K
C432 168-1052-78 16V 1uF K
C433 168-1052-78 16V 1uF K
C435 168-1052-78 16V 1uF K
C436 168-1022-55 1000pF K
C455 042-1764-90 16V 100uF M
C456 043-6401-90 16V 10uF
(NX700E)
C457 043-6401-90 16V 10uF
(NX700E)
C460 168-1032-55 0.01uF K
C491 043-0551-90 6.3V 4.7uF M
C492 043-0551-90 6.3V 4.7uF M
C501 043-0540-00 6.3V 10uF
C504 168-1042-78 16V 0.1uF K
C505 168-1042-78 16V 0.1uF K
C506 043-0540-00 6.3V 10uF
C507 168-1042-78 16V 0.1uF K
C508 043-0551-90 6.3V 4.7uF M
C509 166-2201-50 22pF CH
C510 168-1032-55 0.01uF K
C511 168-1022-55 1000pF K
C512 168-1052-78 16V 1uF K
C513 168-1042-78 16V 0.1uF K
C514 168-4732-78 0.047uF K
C515 165-1063-35 16V 10uF
C516 042-4022-90 6.3V 1000uF
C517 168-1052-78 16V 1uF K
C518 165-4763-15 6.3V 47uF
C520 168-1042-78 16V 0.1uF K
C521 166-1201-50 12pF CH
C522 166-1201-50 12pF CH
C523 166-1011-50 100pF CH
C527 168-1022-55 1000pF K
C528 042-1764-90 16V 100uF M
C530 168-1042-78 16V 0.1uF K
C531 165-2263-35 16V 22uF
C532 168-1042-78 16V 0.1uF K
C534 043-6401-90 16V 10uF
C535 043-6401-90 16V 10uF
C601 168-2222-55 2200pF K
C602 168-2222-55 2200pF K
C603 168-2222-55 2200pF K
C604 168-2222-55 2200pF K
C605 168-2222-55 2200pF K
C606 168-2222-55 2200pF K
C607 168-2222-55 2200pF K
C608 168-2222-55 2200pF K
C610 165-4763-35 16V 47uF
C611 168-1052-78 16V 1uF K
C612 165-1053-65 50V 1uF
C613 042-1545-00 16V 2200uF
C616 172-2241-11 0.22uF
C617 042-1545-00 16V 2200uF
C619 042-1764-90 16V 100uF M
C620 168-1042-78 16V 0.1uF K
C622 168-1042-78 16V 0.1uF K
C623 168-1032-55 0.01uF K
C625 165-4763-35 16V 47uF
C626 168-1042-78 16V 0.1uF K
C630 165-3363-45 25V 33uF
C633 042-1764-90 16V 100uF M
C634 043-6401-90 16V 10uF
C635 043-6401-90 16V 10uF
C636 168-4732-78 0.047uF K
C637 043-6401-90 16V 10uF
C638 043-0540-00 6.3V 10uF
C639 043-0540-00 6.3V 10uF
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
