Clarion NX700 Service Manual

NX700/NX700E
- 34 -
P702 076-0478-55 6P
Q201 125-2041-93 RT1N241M
Q202 125-2041-93 RT1N241M
Q203 192-6053-00 2SC6053
Q204 192-6053-00 2SC6053
Q205 192-6053-00 2SC6053
Q206 192-6053-00 2SC6053
Q207 192-6053-00 2SC6053
Q208 192-6053-00 2SC6053
Q209 192-6053-00 2SC6053
Q210 192-6053-00 2SC6053
Q211 192-4155-49 2SC4155A R,S
Q212 192-4155-49 2SC4155A R,S
Q213 192-4155-49 2SC4155A R,S
Q214 192-4155-49 2SC4155A R,S
Q215 125-0034-96 RT1P436M
Q216 125-0034-96 RT1P436M
Q217 125-0034-96 RT1P436M
Q218 125-0034-96 RT1P436M
Q219 125-2041-96 RT1N436M
Q220 192-4155-49 2SC4155A R,S
Q221 125-2041-96 RT1N436M
Q222 192-4155-49 2SC4155A R,S
Q381 192-4155-49 2SC4155A R,S
Q382 192-4155-49 2SC4155A R,S
Q383 125-2041-93 RT1N241M
Q384 125-3014-90 ISA1602AM1 E,F
Q385 125-3014-90 ISA1602AM1 E,F
Q401 190-1365-50 2SA1365 AF,AG
Q402 125-2041-96 RT1N436M
Q403 190-2071-00 2SA2071
Q404 125-2041-96 RT1N436M
Q451 190-2071-00 2SA2071
Q452 192-4155-49 2SC4155A R,S
Q501 192-4155-49 2SC4155A R,S
Q502 192-4155-49 2SC4155A R,S
Q503 192-4155-49 2SC4155A R,S
Q504 125-0034-93 RT1P241M
Q505 125-3014-90 ISA1602AM1 E,F
Q506 192-4155-49 2SC4155A R,S
Q507 125-2041-92 RT1N141M
Q511 125-2041-96 RT1N436M
Q601 125-4021-90 3CG1260 Q
Q604 125-3014-90 ISA1602AM1 E,F
Q605 192-4155-49 2SC4155A R,S
Q607 192-4155-49 2SC4155A R,S
Q610 125-4021-90 3CG1260 Q
Q612 125-4021-90 3CG1260 Q
Q614 125-3014-90 ISA1602AM1 E,F
Q616 125-2041-96 RT1N436M
Q617 125-2041-96 RT1N436M
Q618 192-4155-49 2SC4155A R,S
Q619 192-4155-49 2SC4155A R,S
Q620 102-3420-50 2SC3420 GR,BL
Q621 125-3014-90 ISA1602AM1 E,F
Q623 125-2041-96 RT1N436M
Q627 125-2041-96 RT1N436M
Q628 192-5824-00 2SC5824
Q634 101-1375-00 2SB1375
Q701 190-1365-50 2SA1365 AF,AG
Q703 125-2041-93 RT1N241M
Q706 125-0034-96 RT1P436M
Q707 125-2041-93 RT1N241M
R101 119-4741-15 1/10W 470k ohm
R102 119-4741-15 1/10W 470k ohm
R103 119-1011-15 1/10W 100 ohm
R104 119-4721-15 1/10W 4.7k ohm
R105 116-2201-15 1/4W 22 ohm
R106 119-1011-15 1/10W 100 ohm
R107 119-1011-15 1/10W 100 ohm
R108 119-0000-05 1/10W 0 ohm JW
R115 119-0000-05 1/10W 0 ohm JW
(NX700E)
R116 119-0000-05 1/10W 0 ohm JW
(NX700)
R200 119-1021-15 1/10W 1k ohm
R203 119-4731-15 1/10W 47k ohm
R204 119-4731-15 1/10W 47k ohm
R207 119-1011-15 1/10W 100 ohm
R216 119-0000-05 1/10W 0 ohm JW
(NX700E)
R220 119-0000-05 1/10W 0 ohm JW
(NX700)
R221 119-2731-15 1/10W 27k ohm
R222 119-2731-15 1/10W 27k ohm
R223 119-5621-15 1/10W 5.6k ohm
R224 119-5621-15 1/10W 5.6k ohm
R225 119-1511-15 1/10W 150 ohm
(NX700E)
R226 119-0000-05 1/10W 0 ohm JW
(NX700)
R227 119-0000-05 1/10W 0 ohm JW
(NX700)
R229 119-0000-05 1/10W 0 ohm JW
(NX700)
R230 119-0000-05 1/10W 0 ohm JW
(NX700)
R231 032-0140-89 1/10W 47k ohm F
R232 032-0140-63 1/10W 27k ohm F
R233 032-0140-89 1/10W 47k ohm F
R234 119-1831-15 1/10W 18k ohm
(NX700)
R235 119-5631-15 1/10W 56k ohm
(NX700)
R236 119-5631-15 1/10W 56k ohm
(NX700)
R237 032-0140-89 1/10W 47k ohm F
R238 032-0140-63 1/10W 27k ohm F
R239 032-0140-89 1/10W 47k ohm F
R240 119-1831-15 1/10W 18k ohm
(NX700)
R241 119-1831-15 1/10W 18k ohm
(NX700)
R242 119-5631-15 1/10W 56k ohm
(NX700)
R243 119-5631-15 1/10W 56k ohm
(NX700)
R244 032-0140-63 1/10W 27k ohm F
R245 119-0000-05 1/10W 0 ohm JW
R246 032-0140-63 1/10W 27k ohm F
R247 119-1831-15 1/10W 18k ohm
(NX700)
R255 119-1031-15 1/10W 10k ohm
R260 032-0140-89 1/10W 47k ohm F
R261 032-0140-89 1/10W 47k ohm F
R263 032-0140-55 1/10W 4.7k ohm F
R264 032-0140-55 1/10W 4.7k ohm F
R267 119-1021-15 1/10W 1k ohm
(NX700E)
R268 119-1021-15 1/10W 1k ohm
(NX700E)
R275 119-4731-15 1/10W 47k ohm
R278 119-4731-15 1/10W 47k ohm
R279 119-1011-15 1/10W 100 ohm
R280 119-1011-15 1/10W 100 ohm
R281 119-6831-15 1/10W 68k ohm
R282 119-6831-15 1/10W 68k ohm
R283 119-4731-15 1/10W 47k ohm
R284 119-4731-15 1/10W 47k ohm
R285 119-2231-15 1/10W 22k ohm
R286 119-2231-15 1/10W 22k ohm
R287 119-2231-15 1/10W 22k ohm
R288 119-2231-15 1/10W 22k ohm
R289 119-2231-15 1/10W 22k ohm
R290 119-2231-15 1/10W 22k ohm
R291 119-2231-15 1/10W 22k ohm
R292 119-2231-15 1/10W 22k ohm
R293 119-1031-15 1/10W 10k ohm
R294 119-1031-15 1/10W 10k ohm
R295 119-3311-15 1/10W 330 ohm
R296 119-1021-15 1/10W 1k ohm
R297 119-1021-15 1/10W 1k ohm
R298 119-3311-15 1/10W 330 ohm
R299 119-3311-15 1/10W 330 ohm
R300 119-1021-15 1/10W 1k ohm
R301 119-1021-15 1/10W 1k ohm
R302 119-3311-15 1/10W 330 ohm
R303 119-3311-15 1/10W 330 ohm
R304 119-1021-15 1/10W 1k ohm
R305 119-1021-15 1/10W 1k ohm
R306 119-3311-15 1/10W 330 ohm
R307 119-3311-15 1/10W 330 ohm
R308 119-1021-15 1/10W 1k ohm
R309 119-1021-15 1/10W 1k ohm
R310 119-3311-15 1/10W 330 ohm
R311 119-2721-15 1/10W 2.7k ohm
R312 119-2721-15 1/10W 2.7k ohm
R319 119-3921-15 1/10W 3.9k ohm
R320 119-3921-15 1/10W 3.9k ohm
R321 119-1021-15 1/10W 1k ohm
R322 119-1021-15 1/10W 1k ohm
R323 119-1031-15 1/10W 10k ohm
R324 119-1031-15 1/10W 10k ohm
R325 119-1021-15 1/10W 1k ohm
R326 119-1021-15 1/10W 1k ohm
R327 119-8231-15 1/10W 82k ohm
R328 119-8231-15 1/10W 82k ohm
R329 119-2231-15 1/10W 22k ohm
R330 119-2231-15 1/10W 22k ohm
R331 119-1021-15 1/10W 1k ohm
R332 119-2231-15 1/10W 22k ohm
R333 119-1021-15 1/10W 1k ohm
R334 119-8221-15 1/10W 8.2k ohm
R335 119-1021-15 1/10W 1k ohm
R336 119-1021-15 1/10W 1k ohm
R338 119-2211-15 1/10W 220 ohm
R339 119-2211-15 1/10W 220 ohm
R350 119-2721-15 1/10W 2.7k ohm
R352 119-2721-15 1/10W 2.7k ohm
R353 119-4731-15 1/10W 47k ohm
R354 119-4731-15 1/10W 47k ohm
R355 119-2721-15 1/10W 2.7k ohm
R356 119-2721-15 1/10W 2.7k ohm
R357 119-4731-15 1/10W 47k ohm
R358 119-4731-15 1/10W 47k ohm
R359 119-2721-15 1/10W 2.7k ohm
R360 119-2721-15 1/10W 2.7k ohm
R361 119-0000-05 1/10W 0 ohm JW
R366 119-0000-05 1/10W 0 ohm JW
R367 119-0000-05 1/10W 0 ohm JW
R368 119-0000-05 1/10W 0 ohm JW
R369 119-0000-05 1/10W 0 ohm JW
R370 119-0000-05 1/10W 0 ohm JW
R371 119-0000-05 1/10W 0 ohm JW
R372 119-0000-05 1/10W 0 ohm JW
R373 119-0000-05 1/10W 0 ohm JW
R374 119-0000-05 1/10W 0 ohm JW
R375 119-0000-05 1/10W 0 ohm JW
R376 119-0000-05 1/10W 0 ohm JW
R377 119-0000-05 1/10W 0 ohm JW
R379 119-0000-05 1/10W 0 ohm JW
R380 119-0000-05 1/10W 0 ohm JW
R381 119-1011-15 1/10W 100 ohm
R382 119-3911-15 1/10W 390 ohm
R383 119-0000-05 1/10W 0 ohm JW
R384 119-1021-15 1/10W 1k ohm
R385 119-4711-15 1/10W 470 ohm
R386 119-2231-15 1/10W 22k ohm
R387 119-2231-15 1/10W 22k ohm
R388 119-1031-15 1/10W 10k ohm
R389 119-1031-15 1/10W 10k ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
