Clarion NX700 Service Manual

NX700/NX700E
- 35 -
R390 119-2231-15 1/10W 22k ohm
R391 119-2231-15 1/10W 22k ohm
R394 119-4731-15 1/10W 47k ohm
R395 119-4721-15 1/10W 4.7k ohm
R396 119-1031-15 1/10W 10k ohm
R397 119-4731-15 1/10W 47k ohm
R398 119-4721-15 1/10W 4.7k ohm
R399 119-4721-15 1/10W 4.7k ohm
R401 119-0000-05 1/10W 0 ohm JW
R402 119-1031-15 1/10W 10k ohm
R403 119-5611-15 1/10W 560 ohm
R406 119-1031-15 1/10W 10k ohm
R407 116-3311-15 1/4W 330 ohm
R409 119-5601-15 1/10W 56 ohm
R410 119-8211-15 1/10W 820 ohm
R411 119-8211-15 1/10W 820 ohm
R412 119-8211-15 1/10W 820 ohm
R421 119-4731-15 1/10W 47k ohm
R422 119-7501-15 1/10W 75 ohm
R423 119-7501-15 1/10W 75 ohm
R424 119-7501-15 1/10W 75 ohm
R425 119-7501-15 1/10W 75 ohm
R429 119-7501-15 1/10W 75 ohm
R431 119-4731-15 1/10W 47k ohm
R451 119-1031-15 1/10W 10k ohm
R452 116-3311-15 1/4W 330 ohm
R453 116-3311-15 1/4W 330 ohm
R468 119-0000-05 1/10W 0 ohm JW
R469 119-0000-05 1/10W 0 ohm JW
R471 119-0000-05 1/10W 0 ohm JW
R472 119-4721-15 1/10W 4.7k ohm
R473 119-4731-15 1/10W 47k ohm
R500 119-2211-15 1/10W 220 ohm
R501 119-2211-15 1/10W 220 ohm
R502 119-1041-15 1/10W 100k ohm
R503 119-1021-15 1/10W 1k ohm
R504 119-1031-15 1/10W 10k ohm
R505 119-0000-05 1/10W 0 ohm JW
R506 119-1031-15 1/10W 10k ohm
(NX700)
R507 119-1011-15 1/10W 100 ohm
R508 119-4721-15 1/10W 4.7k ohm
R509 119-1031-15 1/10W 10k ohm
R510 119-4721-15 1/10W 4.7k ohm
R511 119-1011-15 1/10W 100 ohm
R512 119-1031-15 1/10W 10k ohm
R513 119-4721-15 1/10W 4.7k ohm
R514 119-1031-15 1/10W 10k ohm
(NX700)
R515 119-1031-15 1/10W 10k ohm
R516 119-1011-15 1/10W 100 ohm
R517 119-1011-15 1/10W 100 ohm
R520 119-1021-15 1/10W 1k ohm
R521 119-1031-15 1/10W 10k ohm
R522 119-2231-15 1/10W 22k ohm
R523 119-1031-15 1/10W 10k ohm
R524 119-1031-15 1/10W 10k ohm
R525 119-1031-15 1/10W 10k ohm
R526 119-1041-15 1/10W 100k ohm
R527 119-1031-15 1/10W 10k ohm
R529 119-4721-15 1/10W 4.7k ohm
R530 119-1031-15 1/10W 10k ohm
R531 119-1031-15 1/10W 10k ohm
R537 119-0000-05 1/10W 0 ohm JW
R538 119-4721-15 1/10W 4.7k ohm
R539 119-4721-15 1/10W 4.7k ohm
R540 119-1031-15 1/10W 10k ohm
R541 119-1031-15 1/10W 10k ohm
R542 119-0000-05 1/10W 0 ohm JW
R543 119-2231-15 1/10W 22k ohm
R544 119-0000-05 1/10W 0 ohm JW
R545 119-1031-15 1/10W 10k ohm
(NX700E)
R546 119-1031-15 1/10W 10k ohm
(NX700)
R547 119-1041-15 1/10W 100k ohm
R548 119-1031-15 1/10W 10k ohm
(NX700)
R549 119-1031-15 1/10W 10k ohm
(NX700E)
R550 119-1031-15 1/10W 10k ohm
R551 119-1031-15 1/10W 10k ohm
R554 119-1011-15 1/10W 100 ohm
R555 119-1011-15 1/10W 100 ohm
R556 119-1011-15 1/10W 100 ohm
R557 119-1011-15 1/10W 100 ohm
R558 119-1011-15 1/10W 100 ohm
R559 119-1011-15 1/10W 100 ohm
R560 119-1031-15 1/10W 10k ohm
R561 119-1031-15 1/10W 10k ohm
R562 119-1031-15 1/10W 10k ohm
R563 119-4731-15 1/10W 47k ohm
R564 119-2231-15 1/10W 22k ohm
R566 119-1031-15 1/10W 10k ohm
R567 119-1031-15 1/10W 10k ohm
R568 119-2241-15 1/10W 220k ohm
R569 119-4741-15 1/10W 470k ohm
R570 119-1041-15 1/10W 100k ohm
R571 119-1041-15 1/10W 100k ohm
R572 119-1041-15 1/10W 100k ohm
R573 032-0140-66 1/10W 220 ohm F
R574 119-1041-15 1/10W 100k ohm
R575 119-4731-15 1/10W 47k ohm
R576 119-1031-15 1/10W 10k ohm
R577 119-1031-15 1/10W 10k ohm
R578 119-5621-15 1/10W 5.6k ohm
R579 119-3331-15 1/10W 33k ohm
R580 032-0140-03 1/10W 220k ohm F
R581 119-1041-15 1/10W 100k ohm
R582 032-0140-67 1/10W 3.3k ohm F
R583 119-4721-15 1/10W 4.7k ohm
R584 119-4721-15 1/10W 4.7k ohm
R586 119-1051-15 1/10W 1M ohm
R587 032-0140-16 1/10W 180k ohm F
R589 032-0140-03 1/10W 220k ohm F
R590 032-0140-52 1/10W 33k ohm F
R591 032-0140-56 1/10W 12k ohm F
R592 119-1031-15 1/10W 10k ohm
R593 119-1031-15 1/10W 10k ohm
R594 119-1031-15 1/10W 10k ohm
R595 119-1031-15 1/10W 10k ohm
R597 119-1031-15 1/10W 10k ohm
R599 119-1031-15 1/10W 10k ohm
R601 119-4731-15 1/10W 47k ohm
R603 119-1221-15 1/10W 1.2k ohm
R604 119-1231-15 1/10W 12k ohm
R605 119-3331-15 1/10W 33k ohm
R607 119-4731-15 1/10W 47k ohm
R609 032-0140-50 1/10W 10k ohm F
R610 119-4731-15 1/10W 47k ohm
R611 119-1031-15 1/10W 10k ohm
R612 119-2231-15 1/10W 22k ohm
R613 119-4711-15 1/10W 470 ohm
R614 119-6821-15 1/10W 6.8k ohm
R615 116-1591-15 1/4W 1.5 ohm
R616 116-1591-15 1/4W 1.5 ohm
R618 119-1031-15 1/10W 10k ohm
R619 116-1591-15 1/4W 1.5 ohm
R620 116-1591-15 1/4W 1.5 ohm
R624 119-1031-15 1/10W 10k ohm
R625 119-4711-15 1/10W 470 ohm
R626 116-1221-15 1/4W 1.2k ohm
R628 119-5621-15 1/10W 5.6k ohm
R630 116-1221-15 1/4W 1.2k ohm
R631 119-3321-15 1/10W 3.3k ohm
R632 119-1031-15 1/10W 10k ohm
R634 119-4721-15 1/10W 4.7k ohm
R636 119-6811-15 1/10W 680 ohm
R637 116-1521-15 1/4W 1.5k ohm
R638 119-3321-15 1/10W 3.3k ohm
R639 119-2231-15 1/10W 22k ohm
R640 119-4731-15 1/10W 47k ohm
R641 119-1031-15 1/10W 10k ohm
R642 119-0000-05 1/10W 0 ohm JW
R643 119-4721-15 1/10W 4.7k ohm
R644 119-3321-15 1/10W 3.3k ohm
R645 119-0000-05 1/10W 0 ohm JW
R647 116-6801-15 1/4W 68 ohm
R648 119-0000-05 1/10W 0 ohm JW
R687 119-2201-15 1/10W 22 ohm
R688 119-0000-05 1/10W 0 ohm JW
R689 119-1211-15 1/10W 120 ohm
R690 119-1211-15 1/10W 120 ohm
R691 119-4721-15 1/10W 4.7k ohm
R692 119-4731-15 1/10W 47k ohm
R693 116-3301-15 1/4W 33 ohm
R694 116-3301-15 1/4W 33 ohm
R695 116-3301-15 1/4W 33 ohm
R696 116-5601-15 1/4W 56 ohm
R697 116-5601-15 1/4W 56 ohm
R698 116-5601-15 1/4W 56 ohm
R699 116-3301-15 1/4W 33 ohm
R701 033-2211-15 1/16W 220 ohm J
R702 033-2211-15 1/16W 220 ohm J
R703 033-2211-15 1/16W 220 ohm J
R704 033-4721-15 1/16W 4.7k ohm J
R705 033-4721-15 1/16W 4.7k ohm J
R706 033-2211-15 1/16W 220 ohm J
R707 033-1031-15 1/16W 10k ohm J
R708 033-1221-15 1/16W 1.2k ohm J
R709 033-0000-05 1/16W 0 ohm
R712 033-2211-15 1/16W 220 ohm J
R713 033-2211-15 1/16W 220 ohm J
R714 033-2221-15 1/16W 2.2k ohm J
R715 033-1051-15 1/16W 1M ohm J
R716 033-2211-15 1/16W 220 ohm J
R717 119-1031-15 1/10W 10k ohm
R718 119-2211-15 1/10W 220 ohm
R719 119-2211-15 1/10W 220 ohm
R720 119-2211-15 1/10W 220 ohm
R721 119-1041-15 1/10W 100k ohm
R722 033-1041-15 1/16W 100k ohm J
R724 119-1811-15 1/10W 180 ohm
R725 119-1031-15 1/10W 10k ohm
R726 033-2211-15 1/16W 220 ohm J
R727 033-2211-15 1/16W 220 ohm J
R728 033-2211-15 1/16W 220 ohm J
R729 033-1021-15 1/16W 1k ohm J
R730 119-4731-15 1/10W 47k ohm
R731 119-4731-15 1/10W 47k ohm
R732 119-4731-15 1/10W 47k ohm
R734 119-4731-15 1/10W 47k ohm
R735 119-1031-15 1/10W 10k ohm
R736 033-0000-05 1/16W 0 ohm
R737 119-1021-15 1/10W 1k ohm
R739 119-0000-05 1/10W 0 ohm JW
R740 033-4731-15 1/16W 47k ohm J
R741 033-1041-15 1/16W 100k ohm J
R742 033-1031-15 1/16W 10k ohm J
R743 033-0000-05 1/16W 0 ohm
R744 033-2211-15 1/16W 220 ohm J
R747 033-0000-05 1/16W 0 ohm
R748 119-1011-15 1/10W 100 ohm
R749 119-1011-15 1/10W 100 ohm
R750 119-1011-15 1/10W 100 ohm
R751 119-2211-15 1/10W 220 ohm
R752 119-2211-15 1/10W 220 ohm
R753 033-1041-15 1/16W 100k ohm J
R754 033-1041-15 1/16W 100k ohm J
R755 033-1031-15 1/16W 10k ohm J
R756 032-0163-96 1/2W 27 ohm J
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
