Clarion NX700 Service Manual

NX700/NX700E
- 36 -
R757 032-0163-96 1/2W 27 ohm J
R758 119-4731-15 1/10W 47k ohm
R759 033-1031-15 1/16W 10k ohm J
R760 033-5621-15 1/16W 5.6k ohm J
R761 119-1031-15 1/10W 10k ohm
R762 119-1531-15 1/10W 15k ohm
R763 119-1531-15 1/10W 15k ohm
R766 119-8211-15 1/10W 820 ohm
R767 119-8211-15 1/10W 820 ohm
R768 119-8211-15 1/10W 820 ohm
R769 119-4731-15 1/10W 47k ohm
R772 033-0000-05 1/16W 0 ohm
R779 119-1041-15 1/10W 100k ohm
R780 119-1041-15 1/10W 100k ohm
R781 119-1041-15 1/10W 100k ohm
R782 119-1041-15 1/10W 100k ohm
R783 119-4731-15 1/10W 47k ohm
R997 119-0000-05 1/10W 0 ohm JW
R998 119-0000-05 1/10W 0 ohm JW
(NX700E)
SUP201 060-8057-90 CSA20-141N-T
TH501 002-0315-00 TN10-3U153JT
TM101 073-0785-90 TERMINAL
TM102 073-0785-90 TERMINAL
X101 061-3031-00 4.00MHz
X131 061-3013-00 4.33MHz
(NX700E)
X501 061-3560-90 3.145728MHz AT-
41CD2
X503 060-0100-71 HAS-RP2-14-41-11
X701 061-3534-90 16.92MHz
X702 061-3568-90 32.768kHz
X703 061-3559-90 9.000MHz
PWB 039-3646-00 PWB(WITHOUT
COMPONENTS)
D/D PWB(B3) section
C750 168-2232-55 0.022uF K
C751 168-2232-55 0.022uF K
C752 166-4701-50 47pF CH
C753 168-3322-55 3300pF K
C754 166-3301-50 33pF CH
C755 168-2222-55 2200pF K
C756 168-1522-55 1500pF K
C757 043-0574-90 25V 1.0uF
C758 168-1522-55 1500pF K
C759 043-6400-90 16V 4.7uF K
C760 043-6400-90 16V 4.7uF K
C763 043-6401-90 16V 10uF
C764 043-6401-90 16V 10uF
C765 043-6401-90 16V 10uF
C766 168-3332-78 0.033uF K
C767 168-1022-55 1000pF K
C768 168-1022-55 1000pF K
C769 168-3332-78 0.033uF K
C770 043-6401-90 16V 10uF
C771 043-6401-90 16V 10uF
C772 043-6401-90 16V 10uF
C773 043-0554-90 25V 10uF
C774 043-0554-90 25V 10uF
C775 168-2232-55 0.022uF K
C776 168-2232-55 0.022uF K
C777 166-3301-50 33pF CH
C778 168-2222-55 2200pF K
C779 166-3301-50 33pF CH
C780 168-2222-55 2200pF K
C781 168-1022-55 1000pF K
C782 043-0574-90 25V 1.0uF
C783 166-8211-50 820pF CH
C784 043-6400-90 16V 4.7uF K
C785 043-6400-90 16V 4.7uF K
C788 043-6401-90 16V 10uF
C789 043-6401-90 16V 10uF
C790 043-6401-90 16V 10uF
C791 168-3332-78 0.033uF K
C792 168-1022-55 1000pF K
C793 168-1022-55 1000pF K
C794 168-3332-78 0.033uF K
C795 043-6401-90 16V 10uF
C796 043-6401-90 16V 10uF
C797 043-6401-90 16V 10uF
C798 043-0554-90 25V 10uF
C799 043-0554-90 25V 10uF
IC750 051-3569-90 BD9017KV-E2
IC751 051-3569-90 BD9017KV-E2
J750 074-0881-20 20P
L750 010-3500-92 10uH
L751 010-3408-61 22uH M
L752 010-3408-61 22uH M
L753 010-3500-92 10uH
L754 010-3108-53 330 ohm/100MHz
L755 010-3108-53 330 ohm/100MHz
L756 010-3108-54 600 ohm/100MHz
L757 010-3108-53 330 ohm/100MHz
L758 010-3108-53 330 ohm/100MHz
L759 010-3108-53 330 ohm/100MHz
Q750 125-2041-93 RT1N241M
Q751 125-8029-90 SP8K23 TB
Q752 125-8029-90 SP8K23 TB
Q753 125-2041-93 RT1N241M
Q754 125-8029-90 SP8K23 TB
Q755 125-8029-90 SP8K23 TB
R750 032-0140-76 1/10W 9.1k ohm F
R751 032-0140-00 1/10W 56k ohm F
R752 119-4741-15 1/10W 470k ohm
R753 119-3021-15 1/10W 3k ohm
R754 032-0140-08 1/10W 13k ohm F
R755 119-6221-15 1/10W 6.2k ohm
R756 032-0140-89 1/10W 47k ohm F
R757 032-0140-56 1/10W 12k ohm F
R758 119-2711-15 1/10W 270 ohm
R759 032-0140-22 1/10W 68k ohm F
R760 119-3011-15 1/10W 300 ohm
R761 119-1001-15 1/10W 10 ohm
R762 119-1001-15 1/10W 10 ohm
R765 119-1011-15 1/10W 100 ohm
R766 119-1011-15 1/10W 100 ohm
R769 032-0217-52 1/3W 0.082 ohm
R771 032-0217-51 1/3W 0.039 ohm
R772 032-0140-76 1/10W 9.1k ohm F
R773 032-0140-00 1/10W 56k ohm F
R774 119-4741-15 1/10W 470k ohm
R775 119-6221-15 1/10W 6.2k ohm
R776 032-0140-56 1/10W 12k ohm F
R777 119-4721-15 1/10W 4.7k ohm
R778 032-0140-22 1/10W 68k ohm F
R779 032-0140-50 1/10W 10k ohm F
R780 119-3311-15 1/10W 330 ohm
R781 032-0140-05 1/10W 82k ohm F
R782 119-5611-15 1/10W 560 ohm
R783 119-1001-15 1/10W 10 ohm
R784 119-1001-15 1/10W 10 ohm
R787 119-1011-15 1/10W 100 ohm
R788 119-1011-15 1/10W 100 ohm
R791 032-0217-51 1/3W 0.039 ohm
R793 032-0217-51 1/3W 0.039 ohm
R794 032-0140-90 1/10W 560 ohm F
R795 032-0140-76 1/10W 9.1k ohm F
R796 032-0140-67 1/10W 3.3k ohm F
R797 032-0140-67 1/10W 3.3k ohm F
R802 032-0140-75 1/10W 1.5k ohm F
R803 032-0140-72 1/10W 470 ohm F
PWB 039-3462-00 PWB(WITHOUT
COMPONENTS)
Slide PWB(B4) section
C5603 168-1042-78 16V 0.1uF K
IC5604 051-5806-01 GP1S93
IC5606 051-5806-01 GP1S93
J5001 074-2225-58 8P
P5603 076-0478-52 2P
R5603 119-3311-15 1/10W 330 ohm
R5621 116-5611-15 1/4W 560 ohm
R5625 116-5611-15 1/4W 560 ohm
PWB 039-3501-00 PWB(WITHOUT
COMPONENTS)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
