Clarion PN-2280D-A User Manual

- 13 -
PN-2280D
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C302 042-0562-17 16V10μF
C303 042-0562-17 16V10μF
C305 168-4712-05 470pF
C306 168-4712-05 470pF
C308 166-2201-00 22pF CH
C309 166-2201-00 22pF CH
C312 168-3322-05 3300pF
C313 168-3322-05 3300pF
C314 166-2201-00 22pF CH
C315 166-2201-00 22pF CH
C320 178-2242-78 0.22μF
C321 178-2242-78 0.22μF
C322 043-0309-91 10V 0.82μF
C323 043-0309-91 10V 0.82μF
C324 043-0309-02 10V 0.68μF
C325 043-0309-02 10V 0.68μF
C326 178-2742-78 0.27μF
C327 178-2742-78 0.27μF
C328 178-1832-78 0.018μF
C329 043-0309-02 10V 0.68μF
C330 043-0309-02 10V 0.68μF
C331 178-1832-78 0.018μF
C332 178-3332-78 0.033μF
C333 178-6832-78 0.068μF
C334 178-6832-78 0.068μF
C335 178-3332-78 0.033μF
C336 178-1242-78 0.12μF
C337 178-1842-78 0.18μＦ
C338 178-1842-78 0.18μＦ
C339 178-1242-78 0.12μF
C340 178-6832-78 0.068μF
C341 178-3332-78 0.033μF
C342 178-3332-78 0.033μF
C343 178-6832-78 0.068μF
C350 168-2232-05 0.022μF
(PN-2280D-B ONLY)
C351 168-2232-05 0.022μF
(PN-2280D-B ONLY)
C352 168-2232-05 0.022μF
(PN-2280D-B ONLY)
C400 178-1045-79 0.1μF
C401 178-1045-79 0.1μF
C402 178-1045-79 0.1μF
C403 178-1045-79 0.1μF
C405 043-0277-01 0.022μF
C406 183-1063-32 16V10μF
C407 042-0458-00 50V1μF
C408 168-1022-05 1000pF
C409 178-1045-79 0.1μF
C410 183-4763-32 16V47μF
C411 178-1045-79 0.1μF
C412 178-1045-79 0.1μF
C413 166-1201-00 12pF CH
C414 182-1073-32 16V100μF
C416 166-1201-00 12pF CH
C418 178-1045-79 0.1μF
C421 183-1073-22 10V100μF
C424 166-1011-00 100pF CH
C425 166-1011-00 100pF CH
C426 166-1011-00 100pF CH
C427 166-3301-00 33pF CH
C429 178-1045-79 0.1μF
C431 183-4763-12 6.3V47μF
C432 178-1045-79 0.1μF
C436 042-0562-20 16V47μF
C439 042-0562-20 16V47μF
C451 183-4753-52 35V4.7μF
C456 183-4753-52 35V4.7μF
C460 042-0548-02 10V220μF
C461 183-1073-22 10V100μF
C462 168-1022-05 1000pF
C464 166-1011-00 100pF CH
C465 178-1045-79 0.1μF
C467 166-1011-00 100pF CH
C468 166-1011-00 100pF CH
C470 168-1022-05 1000pF
C473 178-2242-78 0.22μF
C474 178-2242-78 0.22μF
C475 178-4742-78 0.47μF
C500 172-1041-11 0.1μF
C501 042-0571-00 16V2200μF
C502 183-4753-52 35V4.7μF
C503 042-0571-00 16V2200μF
C505 168-2222-05 2200pF
C506 168-2222-05 2200pF
C507 168-2222-05 2200pF
C508 168-2222-05 2200pF
C510 168-2222-05 2200pF
C511 168-2222-05 2200pF
C512 168-2222-05 2200pF
C513 168-2222-05 2200pF
C514 168-2222-05 2200pF
C516 183-1053-62 50V1μF
C517 183-1063-32 16V10μF
C518 172-1041-11 0.1μF
C520 042-0548-03 16V100μF
C521 042-0548-03 16V100μF
C600 178-6832-78 0.068μF
C601 178-6832-78 0.068μF
C602 178-6832-78 0.068μF
C603 178-6832-78 0.068μF
C604 168-1032-05 0.01μF
C605 178-6832-78 0.068μF
C606 178-6832-78 0.068μF
C607 168-2232-05 0.022μF
C608 168-1032-05 0.01μF
C609 178-6832-78 0.068μF
C610 178-6832-78 0.068μF
C612 172-2241-11 0.22μF
C613 172-2241-11 0.22μF
C614 172-2241-11 0.22μF
C615 172-2241-11 0.22μF
C617 042-0505-03 16V2.2μF
C619 183-1053-62 50V1μF
C900 176-1511-00 150pF CH
C903 166-2201-00 22pF CH
C904 166-2201-00 22pF CH
C905 166-2201-00 22pF CH
C906 166-2201-00 22pF CH
C907 166-2201-00 22pF CH
C908 166-2201-00 22pF CH
C909 166-2201-00 22pF CH
C910 166-2201-00 22pF CH
C911 166-2201-00 22pF CH
C912 166-2201-00 22pF CH
C913 166-2201-00 22pF CH
C914 166-2201-00 22pF CH
C915 166-2201-00 22pF CH
C916 166-2201-00 22pF CH
C917 166-2201-00 22pF CH
C918 166-2201-00 22pF CH
C920 176-2201-00 22pF CH
C921 176-2201-00 22pF CH
C922 176-2201-00 22pF CH
C923 176-2201-00 22pF CH
CCT400 050-0122-00 10kΩ×4 J
CCT403 050-0122-03 1kΩ×4
CCT404 050-0122-03 1kΩ×4
CCT405 050-0122-03 1kΩ×4
CCT406 050-0122-03 1kΩ×4
CCT407 050-0122-03 1kΩ×4
CCT408 050-0122-03 1kΩ×4
D250 001-0589-00 1SS145
D251 001-0589-00 1SS145
D252 001-0421-38 MTZJ36
D253 001-0377-44 MA4082M
D401 001-0516-00 MA111
D402 001-0503-45 HZS9B1L
D404 001-0377-38 MA4068M
D405 001-0400-48 HZS9.1JB3
D406 001-0356-00 1SS184
D407 001-0377-69 MA4180M
D408 001-0377-10 MA4030L
D409 001-0516-00 MA111
D411 001-0516-00 MA111
D415 001-0516-00 MA111
D416 001-0330-00 1SS119
D417 001-0516-00 MA111
D418 001-0516-00 MA111
D419 001-0516-00 MA111
D420 001-0516-00 MA111
D421 001-0516-00 MA111
D422 001-0516-00 MA111
D423 001-0516-00 MA111
D424 001-0516-00 MA111
D500 001-0503-31 HZS6 A2L
D503 001-0330-00 1SS119
D504 001-2015-00 RL253
D505 001-0626-00 1A2
D507 001-0377-34 MA4062L
D509 001-0626-00 1A2
D600 001-2606-90 M1FS4
D601 001-2606-90 M1FS4
D602 001-2606-90 M1FS4
D603 001-2606-90 M1FS4
D900 001-0516-00 MA111
IC150 051-4200-90 TA2051FN
IC200 051-5012-00 LC75386
IC300 051-3019-90 NJM2060V
IC301 051-3019-90 NJM2060V
IC302 051-3019-90 NJM2060V
IC303 051-3019-90 NJM2060V
IC400 051-1014-10 TA7291S
IC402 052-1147-30 UPC17718GC-528-
3B9
IC404 051-3020-90 NJM4565V
IC600 051-3019-90 NJM2060V
IC601 051-2023-01 TA8260AH
J250 074-1013-00 12P
J400 074-1186-18 18P
J500 074-0898-20 20P
J501 074-1185-00 16P
L100 010-2230-76 22μH
L101 010-2230-76 22μH
L102 010-2230-64 2.2μH
L150 010-2003-04 COIL
L151 010-2230-76 22μH
L152 010-6004-40 2.2mH J
L400 010-2230-76 22μH
L401 010-2230-76 22μH
P400 076-0461-20 20P
P401 076-0368-20 20P
P402 076-0540-12 12P
P403 076-0540-16 16P
Q100 125-2005-01 UN2211
Q101 100-1298-00 2SA1298
Q102 125-2005-01 UN2211
Q103 125-9003-02 IMD3
Q104 100-1298-00 2SA1298
Q105 125-2005-01 UN2211
Q251 125-9006-00 IMX1
Q252 103-0601-00 2SD601A
Q253 125-2005-01 UN2211
Q254 125-0001-01 UN2111
Q400 103-2012-00 2SD2012
Q402 125-9003-02 IMD3
Q403 102-2458-51 2SC2458Y.GR.BL
Q404 102-2458-51 2SC2458Y.GR.BL
Q405 100-1428-00 2SA1428
Q406 125-2004-06 RN1406
Q407 103-2012-00 2SD2012
Q412 103-1858-00 2SD1858
Q415 125-9003-02 IMD3
Q416 103-2012-00 2SD2012
Q417 125-0006-00 UN2110
