- 9 -
PN-2280D
1 960-4294-14 DECK PLATE ASSY 1
2 960-4261-05 HEAD PLATE ASSY 1
3 960-4262-03 FF/REW-P-ASSY 1
4 960-4263-03 IDLER-P-ASSY L 1
5 960-4264-03 IDLER-P-ASSY R 1
6 960-4266-05 MODE PLATE ASSY 1
7 960-4269-05 ROLLER ASSY F 1
8 960-4270-05 ROLLER ASSY R 1
9 960-4348-03 REEL ASSY F 1
10 960-4349-03 REEL ASSY R 1
11 960-4298-09 EJECT SUB ASSY 1
11-1 750-2948-01 SWITCH PLATE SPRING 1
12 960-4338-07 BOTTOM SUB ASSY 1
12-1 960-4295-02 BOTTOM-P-ASSY 1
12-2 099-9926-01 BOTTOM PWB 1
(WITHOUT COMPONENT)
12-3 013-3951-11 SWITCH(MODE) 1
12-4 013-3953-01 SWITCH(METAL) 1
12-5 051-1776-00 IC 1
12-6 746-0767-00 WASHER 2
13 960-4282-06 DETECT SUB ASSY 1
14 960-4301-02 PLAY LINK ASSY 1
15 039-1436-00 SIDE PWB 1
(WITHOUT COMPONENT)
16 990-0713-00 REAR PWB ASSY 1
(WITH COMPONENT)
16-1 013-3906-00 SWITCH(TAPE IN) 1
16-2 074-1104-20 OUTLET SOCKET(20P) 1
16-3 076-0368-10 PLUG(10P) 1
16-4 039-0489-00 REAR PWB 1
17 SMA-130-100 MAIN MOTOR ASSY 1
18 SMA-131-100 POWER MOTOR ASSY 1
19 011-0307-34 HEAD 1
20 602-0118-00 BELT 1
21 604-0046-00 TENSION PULLEY 1
22 606-0101-08 PACK GUIDE 1
23 610-0342-01 HEAD-P-ROLLER 1
24 610-0343-00 GUIDE-A-ROLLER 1
25 611-0091-02 FLYWHEEL 2
26 613-0662-00 IDLER GEAR 2
27 613-0286-02 FF/REW GEAR 2
28 613-0288-01 HELICAL GEAR 1
29 613-0289-01 GEAR A 1
30 613-0337-00 POWER GEAR 1
31 630-2597-01 CHANGE LINK 1
32 630-2598-05 EJECT LINK 1
33 630-2600-01 ADJUST LINK 1
34 630-2601-02 MOTOR PLATE 1
35 630-2626-05 PWB FRAME 1
36 630-2605-02 GUIDE ARM 1
37 631-1992-02 PACK STOPPER 1
38 631-1993-01 SLIDE BUSH 2
39 716-0484-00 SCREW(M2×2.5) 13
40 716-1676-00 PWB SCREW(M2.6×6) 2
41 716-0833-10 SCREW(M2×5.6) 2
42 746-0624-00 WASHER 2
43 746-0724-00 WASHER 6
44 746-0761-00 WASHER 2
45 746-0762-00 WASHER 1
46 750-2946-02 PINCH SPRING 1
47 750-2947-03 EJECT-P-SPRING 1
48 750-2949-00 SLIDE SPRING 2
49 750-3017-02 IDLER-P-SPRING 1
50 800-4910-60 WIRE(BLK) 1
51 802-4911-60 WIRE(RED) 1
52 806-4914-60 WIRE(BLU) 1
53 809-4914-60 WIRE(WHT) 1
54 074-0898-10 OUTLET SOCKET(10P) 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
