- 12 -
PN-2280D
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
5 750-3202-00 CENTER SPRING-B 1
6 750-3096-01 DR-SPRING R 1
7 750-3164-00 DR-SPRING LR 1
8 750-3188-00 DR-SPRING F-B 1
9 750-3201-00 DR-SPRING F-R 1
10 966-0308-23 CHASSIS-ASSY 1
11 966-0309-22 L-DISC-G-ASSY 1
12 966-0310-21 SHIFT-P-CH-ASSY 1
13 HBS-430-100 GEAR PLATE ASSY 1
14 966-0312-21 SHIFT-PLATE-ASSY 1
15 966-0358-21 DRIVE-L-PLATE-ASSY 1
16 966-0359-21 SIDE-L-PLATE-ASSY 1
17 SMA-147-100 MOTOR ASSY(LOADING) 1
18 013-3879-01 CHUCKING SWITCH 1
19 804-4910-60 VINYL-COAT-WIRE(YEL) 1
20 039-0586-01 CHUCKING SWITCH PWB 1
(WITHOUT COMPONENT)
21 039-0588-01 SENSOR PWB 1
(WITHOUT COMPONENT)
22 060-0252-01 PHOTO-TR 3
23 345-7513-01 CLAMPER SHEET 1
24 345-7514-00 SENSOR PWB SHEET 1
25 802-4910-60 VINYL-COAT-WIRE(RED) 1
26 620-0485-20 FRONT PLATE 1
27 620-0488-20 S-L-LINK PLATE 1
28 620-0489-02 MOTOR PLATE 1
29 802-4904-60 VINYL-COAT-WIRE(RED) 1
30 620-0492-20 MOTOR BRACKET 1
31 801-4910-60 VINYL-COAT-WIRE(BRN) 1
32 620-0697-02 CD-MECH-BRKT 1
33 800-4910-60 VINYL-COAT-WIRE(BLK) 1
34 621-0402-01 U-DISC GUIDE-F 1
35 621-0243-02 ROLLER SLEEVE 2
36 800-4904-60 VINYL-COAT-WIRE(BLK) 1
37 750-3189-00 SIDE-L-SPRING 1
38 750-3098-00 L-LINK SPRING 1
39 750-3094-00 S-ARM SPRING 1
40 621-0248-07 RACK GEAR 1
41 621-0249-02 ROLLER GEAR 1
42 621-0250-01 DAMPER HOLDER 4
43 750-3092-03 SHIFT SPRING 1
44 750-3091-03 ROADING-SPRING-R 1
45 750-3090-02 ROADING-SPRING-L 1
46 746-0877-02 WASHER 2
47 746-0762-00 WASHER 1
48 746-0712-03 WASHER 1
49 743-1500-10 E-RING 3
50 621-0258-03 LOADING ROLLER 2
51 716-1742-00 SCREW(M2×5) 1
52 716-1704-00 SCREW(M2×7) 1
53 716-1677-00 SCREW(M2×5) 1
54 716-1507-00 SCREW(M2×3) 2
55 622-1072-05 ROLLER SHAFT 1
56 716-1468-00 SCREW(M2×2.5) 2
57 622-1219-01 SHIFT ROLLER 1
58 714-2603-81 SCREW(M2.6×3) 5
59 629-0058-00 DAMPER-VA 4
60 714-2003-81 SCREW(M2×3) 8
■ELECTRICAL PARTS LIST
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
Some parts depend on each model.The model name is specified in the
description.
Main PWB section(B1)
BL100 880-1726E FM TUNER
BL150 880-1517E AM TUNER
C102 178-1045-79 0.1μF
C103 043-0277-01 0.022μF
C105 178-3932-78 0.039μF
C106 178-3932-78 0.039μF
C108 183-4763-32 16V47μF
C109 178-1045-79 0.1μF
C111 178-4742-78 0.47μF
C112 178-4742-78 0.47μF
C120 178-1022-78 1000pF
C121 176-1011-00 100pF CH
C122 176-1011-00 100pF CH
C130 166-1011-00 100pF CH
C150 176-1007-00 10pF CH
C152 042-0427-02 16V33μF
C153 178-1045-79 0.1μF
C154 168-1022-05 1000pF
C155 168-2232-05 0.022μF
C156 178-1242-78 0.12μF
C157 166-5601-00 56pF CH
C158 183-1063-32 16V10μF
C159 178-5632-78 0.056μF
C160 042-0504-06 16V3.3μF
C161 178-8232-78 0.082μF
C210 042-0562-17 16V10μF
C211 042-0562-17 16V10μF
C212 042-0562-17 16V10μF
C213 042-0562-17 16V10μF
C214 042-0562-36 50V1μF
C215 042-0562-36 50V1μF
C217 178-1242-78 0.12μF
C218 178-1242-78 0.12μF
C220 168-1532-05 0.015μF
C221 168-1532-05 0.015μF
C222 168-3312-05 330pF
C223 168-3312-05 330pF
C224 042-0562-17 16V10μF
C225 042-0562-17 16V10μF
C226 178-3332-78 0.033μF
C250 168-1022-05 1000pF
C251 168-1022-05 1000pF
C252 168-1022-05 1000pF
C253 168-2232-05 0.022μF
C255 042-0562-17 16V10μF
C256 042-0562-17 16V10μF
C257 042-0562-17 16V10μF
C258 042-0562-17 16V10μF
C300 042-0562-17 16V10μF
C301 042-0562-17 16V10μF
C162 168-4712-05 470pF
C163 168-2732-05 16V 0.027μF
C164 168-4712-05 470pF
C165 166-5601-00 56pF CH
C166 166-4701-00 47pF CH
C167 168-4722-05 4700pF
C168 168-1032-05 0.01μF
C169 178-4732-78 0.047μF
C170 168-1032-05 0.01μF
C171 168-2232-05 0.022μF
C172 183-4753-52 35V4.7μF
C173 183-4753-52 35V4.7μF
C174 178-6832-78 0.068μF
C175 178-1032-78 0.01μF
C177 178-1042-78 0.1μF
C180 183-4763-32 16V47μF
C200 042-0505-04 10V33μF
C202 178-1842-78 0.18μＦ
C203 042-0562-36 50V1μF
C204 042-0562-36 50V1μF
C205 042-0562-36 50V1μF
C206 042-0562-36 50V1μF
C207 178-1842-78 0.18μＦ
C208 042-0562-36 50V1μF
C209 042-0562-36 50V1μF
To Next Page
