- 15 -
PN-2280D
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Display PWB section(B2)
C700 043-0206-61 0.1μF F
C701 043-0206-63 0.022μF F
C702 043-0206-63 0.022μF F
C703 043-0206-28 47pF SL
FL700 379-4023-20 VFD
IC700 051-6011-10 LC75741G
J700 074-1151-12 12P
J701 074-1151-16 16P
L700 010-2230-76 22μH
PL700 017-0420-28 14V40mA(WHITE)
PL701 017-0420-28 14V40mA(WHITE)
PL702 017-0420-28 14V40mA(WHITE)
PL703 017-0420-28 14V40mA(WHITE)
PL704 017-0420-28 14V40mA(WHITE)
PL705 017-0420-28 14V40mA(WHITE)
R700 111-4741-91 1/4WS 470kΩ
R701 111-1031-91 1/4WS 10kΩ
S700 013-6200-60 SKPLAA
S701 013-6200-60 SKPLAA
S702 013-6200-60 SKPLAA
S703 013-6200-60 SKPLAA
S704 013-6200-60 SKPLAA
S705 013-6200-60 SKPLAA
S706 013-6200-60 SKPLAA
S707 013-6200-60 SKPLAA
S708 013-6200-60 SKPLAA
S709 013-6200-60 SKPLAA
S710 013-6200-60 SKPLAA
S711 013-6200-60 SKPLAA
S712 013-6200-60 SKPLAA
S713 013-6200-60 SKPLAA
S714 013-6200-60 SKPLAA
S716 013-6200-60 SKPLAA
VR700 016-0010-08
CD mechanism/CD PWB section(B3)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C1 178-1032-78 0.01μF
C2 178-1042-78 0.1μF
C3 178-1032-78 0.01μF
C4 182-4763-13 6.3V47μF
C5 178-1042-78 0.1μF
C6 182-4763-13 6.3V47μF
C7 178-1042-78 0.1μF
C8 176-1801-00 18pF CH
C9 176-2096-00 2pF CJ
C10 182-1073-15 6.3V100μF
C12 178-1042-78 0.1μF
C13 178-1042-78 0.1μF
C14 178-1042-78 0.1μF
C15 176-1007-00 10pF CH
C16 178-2212-78 220pF
C17 178-1032-78 0.01μF
C18 178-1042-78 0.1μF
C19 178-2212-78 220pF
C20 178-4745-79 0.47μF
C21 178-1032-78 0.01μF
C22 178-2212-78 220pF
C23 178-1042-78 0.1μF
C24 178-1522-78 1500pF
C25 178-4732-78 0.047μF
C26 178-1042-78 0.1μF
C27 178-1042-78 0.1μF
C28 178-1042-78 0.1μF
C29 178-1042-78 0.1μF
C30 178-6812-78 680pF
C31 176-1511-00 150pF CH
C32 178-1042-78 0.1μF
C33 176-1007-00 10pF CH
C34 176-1007-00 10pF CH
C35 178-6812-78 680pF
C36 176-1511-00 150pF CH
C37 178-1042-78 0.1μF
C38 178-1042-78 0.1μF
C39 182-1063-33 16V10μF
C40 178-1042-78 0.1μF
C41 182-1063-33 16V10μF
C42 182-1063-33 16V10μF
C43 182-1063-33 16V10μF
C44 182-1063-33 16V10μF
C45 182-1073-33 16V100μF
C48 178-2225-79 2200pF
D1 001-0563-00 GL380
D2 001-0563-00 GL380
D3 001-0563-00 GL380
D5 001-0528-32 MA8056-M
IC1 051-1014-10 TA7291S
IC2 051-6015-05 BA6392FP
IC3 051-1971-00 CXA1610M
IC4 051-6318-00 CXD2548R
IC5 052-5018-03 μPD78002BGC-
650-AB8
J1 074-1143-06 6P
J2 074-1138-17 17P
L1 010-2155-03 10μH
Q1 101-1237-50 2SB1237QR
Q3 103-1754-64 2SD1754A-P,Q
Q4 125-0002-02 RN2402
Q5 125-2004-02 RN1402
R1 117-8231-10 1/10W 82kΩ
R2 117-1031-10 1/10W 10kΩ
R3 111-2711-91 1/4WS 270Ω
R4 117-1031-10 1/10W 10kΩ
R5 117-1231-10 1/10W 12kΩ
R6 117-1031-10 1/10W 10kΩ
R7 117-6821-10 1/10W 6.8kΩ
R8 117-5631-10 1/10W 56kΩ
R9 117-2231-10 1/10W 22kΩ
R10 117-1011-10 1/10W 100Ω
R11 117-2201-10 1/10W 22Ω
R12 117-1041-10 1/10W 100kΩ
R13 117-3331-10 1/10W 33kΩ
R14 117-3631-10 1/10W 36kΩ
R15 117-1241-10 1/10W 120kΩ
R16 117-3631-10 1/10W 36kΩ
R17 117-1031-10 1/10W 10kΩ
R18 117-1041-10 1/10W 100kΩ
R19 117-1051-10 1/10W 1MΩ
R20 117-1031-10 1/10W 10kΩ
R21 117-3321-10 1/10W 3.3kΩ
R22 117-6821-10 1/10W 6.8kΩ
R23 117-1051-10 1/10W 1MΩ
R24 117-1041-10 1/10W 100kΩ
R25 117-4741-10 1/10W 470kΩ
R26 117-1231-10 1/10W 12kΩ
R27 117-1231-10 1/10W 12kΩ
R28 117-1231-10 1/10W 12kΩ
R29 117-4711-10 1/10W 470Ω
R30 117-1231-10 1/10W 12kΩ
R31 117-1231-10 1/10W 12kΩ
R32 117-1231-10 1/10W 12kΩ
R34 117-4731-10 1/10W 47kΩ
R35 117-1041-10 1/10W 100kΩ
R36 117-1041-10 1/10W 100kΩ
R37 117-1041-10 1/10W 100kΩ
R38 117-4741-10 1/10W 470kΩ
R41 117-4741-10 1/10W 470kΩ
R42 117-4741-10 1/10W 470kΩ
R43 117-4741-10 1/10W 470kΩ
R44 117-4741-10 1/10W 470kΩ
R45 117-4731-10 1/10W 47kΩ
R48 117-3911-10 1/10W 390Ω
X1 061-1087-50 16.9344MHz
X2 060-0322-00 4.0MHz
Sensor PWB section(B4)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Q101 060-0252-01 PT4850F
Q102 060-0252-01 PT4850F Q103 060-0252-01 PT4850F
Chucking SW PWB section(B5)
REF No. PART No. DESCRIPTION
S2 013-3879-01 SPPB12
Limit SW PWB section(B6)
REF No. PART No. DESCRIPTION
S1 013-7100-00 SPPB11
Tape mechanism/Side PWB section(B7)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C1 178-5612-78 560pF
C2 178-5612-78 560pF
C3 178-5612-78 560pF
C4 178-5612-78 560pF
C5 172-1231-11 0.012μF
C6 172-1231-11 0.012μF
C7 172-4731-11 0.047μF
C8 172-4731-11 0.047μF
C9 183-1053-61 50V1μF
C10 178-5612-78 560pF
C11 178-5612-78 560pF
C12 178-1042-78 0.1μF
