Clarion PN-2280D-A User Manual

- 16 -
PN-2280D
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C13 178-1042-78 0.1μF
C14 178-4722-78 4700pF
C15 183-2263-31 16V22μF
C16 178-1032-78 0.01μF
C17 183-1043-61 50V0.1μF
C18 183-4753-51 35V4.7μF
C20 176-2201-50 22pFCH
C21 176-2201-50 22pFCH
C22 176-2201-50 22pFCH
C23 176-2201-50 22pFCH
IC1 051-1777-00 HA12163
L1 010-2198-26 0.047μH
L2 010-2198-26 0.047μH
R1 117-2731-10 1/10W 27kΩ
R2 117-2731-10 1/10W 27kΩ
R3 117-2731-10 1/10W 27kΩ
R4 117-2731-10 1/10W 27kΩ
R5 117-1811-10 1/10W 180Ω
R6 117-1811-10 1/10W 180Ω
R7 117-3341-10 1/10W 330kΩ
R8 117-3341-10 1/10W 330kΩ
R9 117-1131-10 1/10W 11kΩ
R10 117-1131-10 1/10W 11kΩ
R11 117-1531-10 1/10W 15kΩ
R12 117-1531-10 1/10W 15kΩ
R13 032-0098-03 1/10W 18kΩ±2%
R14 117-3331-10 1/10W 33kΩ
R15 117-1831-10 1/10W 18kΩ
R16 117-1841-10 1/10W 180kΩ
R17 117-4731-10 1/10W 47kΩ
R18 117-1241-10 1/10W 120kΩ
R19 117-2231-10 1/10W 22kΩ
R20 117-2231-10 1/10W 22kΩ
R21 117-2231-10 1/10W 22kΩ
R22 117-1031-10 1/10W 10kΩ
R23 117-2231-10 1/10W 22kΩ
VR1 012-4431-06 10kΩ
VR2 012-4431-06 10kΩ
Bottom PWB section(B8)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
IC2 051-1776-00 NJL5801K SW1 013-3953-01 SPPB32
SW2 013-3951-11
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Rear PWB section(B9)
P5 076-0368-10 10P
P6 074-1104-20 20P
R24 111-5611-91 1/4WS 560Ω
SW3 013-3906-00 SPPB51
