Menu
Main Menu Descriptions
Name Description View
Pump
Controller
The pump controller menu allows
the technician to adjust settings,
enable and disable options, teach
(learn) sensors, and view real-time
readings related to the hydraulic
pump motor and controller.
Refer to the Service Manual for
additional information.
A0MP2BCPTVEP1.11 >>
A0MP2BCPTVEP1.11 >>
Parameter Change
Set Options
Set Model
Adjustment
Special Adjust
Hardware Setting
Program VACC
Tester
A0MP2BCPTVEP1.11 >>
A0MP2BCPTVEP1.11 >>
Alarm
Clear EEPROM
Steer
Controller
(EPS)
The steer controller menu allows
the technician to adjust settings,
enable and disable options, teach
(learn) sensors, and view real-time
readings related to the steer motor
and controller.
Refer to the Service Manual for
additional information.
EPSDC0S EP0.08 >>
EPSDC0S EP0.08 >>
Parameter Change
Set Options
Set Model
Adjustment
Special Adjust
Hardware Setting
Program VACC
Tester
EPSDC0S EP0.08 >>
EPSDC0S EP0.08 >>
Alarm
Clear EEPROM
BMS
Management
The battery management system
(BMS) menu allows the technician
to view the battery readings for the
lithium-ion BMS.
Refer to the Service Manual for
additional information.
BMS MAIN INFO. (LFP04.1.2)
BMS MAIN INFO. (LFP04.1.2)
Voltage : 49. 3V
Current : -2. 0A
SOC : 42%
Limit : None
CAN : Normal
Capacity : 150. 9AH
Temp. Hi : +27C
Temp. Low : +26C
Present Fault:
None
Single Max Volt : 3. 295V NO. : 2
Single Min Volt : 3. 289V NO. : 6
