Lithium-Ion Battery
Battery Removal and Installation
Removing and Installing the Battery:
1. Park the lift truck.
2. Turn the lift truck OFF.
3. Remove the left side panel (1).
4. Remove the bracket (2) and the two bolts (3).
5. Disconnect the power cables (4) and the
communication cables (5). Position the
cables out of the way.
6. Remove the battery (6) from the lift truck.
7. Installation is the reverse procedure of
removal.
