7/2014 A - 5 56091130 - CA30 20B
ENGLISH - AINSTRUCTIONS FOR USE
TECHNICAL DATA
Model CA30 20B
Machine Height 980mm
Solution tank capacity 40 litre
Recovery tank capacity 40 litre
Diameter of transport wheel 200mm
Diameter of guide wheel 76mm
Power of vacuum system motor 350w
Maximum gradient when working 2% (Max)
Sound pressure level at workstation 70dB(A) ±3dB(A)
Standard batteries (2×12V) 24V 105Ah AGM
Battery compartment size (W x L x H) 340 x 330 x 260mm(Max)
Vacuum system circuit capacity 1200 mm H
2
O
Cleaning width 510mm
Squeegee width 790mm
machine maximum length 1100mm
Machine width without squeegee 540mm
Brush diameter 510mm
Weight with batteries and with empty tanks 128kg
Gross weight of the machine ready for use 168kg
Brush motor power 560W
Brush speed 150rpm
Brush /pad-holder Maximum pressure 35kg(Max)
Packing size (Lx W x H) 1200 x 610 x 1170mm
