7/2014 D - 9 56091130 - CA30 20B
PARTS LIST
BRUSH SYSTEM
Item Ref. No. Qty Description
1 VF90257 1 20” Brush Motor
2 VF90424 2 Nut M20
3 VF90282 1 Solenoid Valve Kit
4 VF90418 1 Solenoid Valve Bracket
5 VV13650A 4 Screw M4x10
6 VV10114 1 Clamp
7 VF90440 1 Tubing L=260mm
8 VF90430 2 Brass Spacer
9 VF90404 1 Connect Plate
10 VF90421 4 Spacer
11 VF14555 4 Screw, Shoulder M12x50
12 VF14238 2 Screw, Shoulder M12x30
13 VF14530 2 Screw, Shoulder M6×40
14 VF85134 2 Spacer
15 VF85107 2 Bumper Roller
16 VF90422 1 Spacer
17 VF90413A 1 20” Brush Deck
18 VF14506 2 Nut Lock M6
19 GT13067 4 Screw, Shoulder M8x25
20 VF90444 1 Driven Pulley Kit
21 ZD45425 2 Bearing 6204 Lu
22 VF90423 1 Clamp Sleeve
23 VV13650A 2 Screw M4x10
24 VV20291 2 Washer,Lock,Ø4
25 VF90437 1 Brush Spring Clip
26 VF90409 1 Driven Pulley
27 VF90425 1 Driven Pulley Shaft
28 VF90415 1 Vibration Gasket
29 VF13534 1 Washer Ø8.4x Ø18x 2
30 VV20298 1 Washer,Lock,Ø8
Item Ref. No. Qty Description
31 VV13604 1 Screw, Shoulder M8x20
32 VF90408 1 Belt
33 VF13503 4 Nut Lock M8
34 VF14057A 3 Nut , M12
35 VF13541 3 Washer, Lock Ø12
36 VF13538 2 Washer ,Ø12xø24x2
37 VF90456 1 Connect Plate B
38 VF90403 1 20” Frame
39 VV20298 4 Washer,Lock,Ø8
40 VV13604 4 Screw, M8x20
41 VF90445 1 Tension Wheel Kit
42 VF14516 1 Nut Lock M8
43 VF13535 1 Washer Ø8xø20x2
44 VF999821A 2 Bearing 6002
45 VF90426 1 Tension Wheel
46 VF80209 1 Spacer
47 VF80214 1 Spacer
48 VF13503 2 Nut Lock M8
49 VF13534 2 Washer Ø8.4x Ø18x 2
50 VF90427 1 Rod, Tension Wheel
51 VF80232 1 Spring
52 VF80235 1 Spacer
53 VF14255 1 Screw, M12x65
54 GT13066 1 Screw, Shoulder M8x55
55 VF90439 2 Bushing Tension Wheel
56 VF90438 2 Screw, Shoulder M8x30
57 VF90417 1 20”Brush
58 VF90454 1 20” Pad
To Next Page
