7/2014 D - 11 56091130 - CA30 20B
PARTS LIST
SQUEEGEE SYSTEM
Item Ref. No. Qty Description
1 VF14547 1 Screw Lock M10
2 VF85104 1 Hand Wheel
3 VF13534 1 Washer Φ8.4x Φ18x 2
4 VF14503 3 Nut M8
5 VF90133 1 Spacer
6 VF90110 1 Back-Squeegee-Support
7 VF14516 2 Nut Lock M8
8 VF14506 3 Nut M6
9 VF13533 1 Washer Flat Ø6
10 VF90111 1 Front-Squeegee-Support
11 VF85336 2 Washer Nylon
12 VF90130 1 Screw Shoulder
13 VF81210 2 Knob
14 VF84228 2 Screw Shoulder M8
15 VF82112 1 Spacer
16 VF14233 1 Screw
17 VF90109 1 Squeegee-Support
18 VF90135 1 20” Squeegee Kit
19 VF90136 2 Squeegee Roll Wheel Kit
20 VV20203 2 Nut Lock
21 VF81219 2 2” Wheel
22 VF81222 2 Bolt Shoulder 5/16”
23 VF90118 1 20” Strap, Squeegee Front
24 VF90137 2 Bumper Roller Kit
25 VF14530 2 Screw M6×40
26 VF85107 2 Bumper Roller
27 VF85134 2 Spacer
28 VF90119 1 20” Blade Front
29 VF90120 1 20” Blade Rear
30 VF85420 2 Wing Nut M8×30
31 VF90117 1 Squeegee 20”
32 VF90127 2 Squeegee Screw
33 VF90139 1 20” Strap, Squeegee Back Kit
34 VF14305 1 Screw M5×60
35 VF90121 1 Hook
36 VF81208A 2 Rivet Ø4×5
37 VF81218A 1 Latch Hood
38 GT13022 1 Nut Lock M5
39 VF90106 1 20” Strap, Squeegee Back
