Clarke 510B User Manual

A - 6 CA30 20B - 56091130 7/2014
INSTRUCTIONS FOR USEA - ENGLISH
MACHINE COMPONENTS
Safety switch button1.
Handle2.
Control panel3.
Serial number plate/Technical data4.
Control cover5.
Cable holder (*)6.
Battery charging indication light7.
Reset switch8.
Battery connector9.
Battery cover10.
Drain hose11.
Squeegee lift cable12.
Battery connector safety cover13.
Squeegee lift handle14.
Drain cap15.
Squeegee knob16.
Squeegee clip17.
Squeegee blade18.
Squeegee bracket19.
Squeegee adjusting knob20.
Squeegee rear support frame21.
Squeegee front support frame22.
Cup holder23.
Recovery tank cover handle24.
Recovery tank lid25.
Recovery tank26.
Solution fi ll27.
Brush deck28.
Brush / pad-holder29.
Vacuum motor30.
Brush motor31.
8” wheel32.
Battery33.
Vacuum tube34.
Charger (*)35.
Float fi lter36.
Water level site tube37.
(*) applicable only to machines already installed with on-board charger (optional)
CONTROL PANEL
Battery charge indication light (green when saturated)38.
Battery exhausted indication light (red)39.
Battery exhausted indication light (red)40.
Power switch41.
Vacuum switch42.
Hour meter (optional)43.
Solution switch44.
