7/2014 D - 3 56091130 - CA30 20B
PARTS LIST
TANK SYSTEM
Item Ref. No. Qty Description
1 VF90412A 1 Handle, Recovery Tank Cover
2 VF90503A 1 Recovery Tank Cover
3 VA80758 3 Screw
4 VF90504 1 Gasket
5 VF90619A 1 Tank Filter Net Kit
6 VF90612A 1 Filter Cover
7 VF90614 1 Inlet Strap
8 VF90616 2 Screw Ta3.5x12
9 VA13483A 2 Washer
10 VA13477 2 Screw St4x15
11 VF90611 1 Filter Support
12 VF90501A 1 Tank
13 VF90011-CL 1 Logo Label
14 VF90613A 1 Floating Ball Of Water Level
15 VF90617 1 Inspection Tube
16 RD60764 2 Elbow, 90º, Brass
17 VF86135 1 Gasket
18 VF90520 1 Vacuum Motor
19 VF85319 1 Acoustic Insulation Pipe
20 VF90523 1 Top Gasket Of Suction Motor
21 VF13503 1 Nut Lock M8
22 VF90511 1 Cover, Vacuum Motor
23 VF14543 Washer
24 VV13601 3 Washer,Lock,Ø5
25 VA52245 3 Screw M5*15
26 VF14066 1 Nut M8
27 VF90434 1 Screw M8*65
28 VF90513 1 Outlet O-Ring
29 VF90507 1 Outlet Cover
30 VF90533 2 Battery Spacer Panel
31 VF90312 1 2.5” Wheel Kit
32 VF14551 2 Ring D 17
33 VF90306 1 2.5” Wheel
Item Ref. No. Qty Description
34 VF90308 2 2.5” Hub Cap
35 VF90314 1 Transport Wheel Shaft
36 VF90510 2 Retainer Plate
37 VF90235 2 Screw Tm4x10
38 VF90508 2 Suction Hose
39 VF90246 1 Battery Cable Kit
40 VF90231 1 Gasket
41 VF90214 2 Seal Plate Cover
42 VF90217 2 Seal Plate
43 VA80758 4 Screw
44 VF90529 1 Suction Tube Connecter
45 VF90528 1 Drain Hose Connector
46 VF90512 3 Suction Tube Gasket
47 VF90509 2 Sealing Knob
48 VA20304 4 Clamp
49 VF90534 1 Float Kit
50 VF90530 1 Cage, Float Complete
51 VF90526 1 Float Bracket
52 VF85124 1 Float
53 VF90527 1 Float Bracket Cover
54 VF90218 1 Control Seal Gasket
55 VF90401 1 Drain Hose Connecter
56 VF83150 1 Holder, “U” Hose
57 VF90443 1 Drain Hose-38
58 VF90235 2 Screw Tm4x10
59 VA13483 2 Washer 4
60 VF90514 1 Battery Bracket
61 2 Battery
62 GT13054 4 Screw Tm5x12
63 VF90418A 1 Battery Cover
64 VF90254 1 Motor Cable Assembly
65 VF90247 1 Power Cable
66 VF90026 1 Warning Label
To Next Page
