7/2014 D - 5 56091130 - CA30 20B
PARTS LIST
CONTROL SYSTEM AND ELECTRICAL SYSTEM
Item Ref. No. Qty Description
1 VF90203A 2 Safety Switch Knob
4 VF90286 4 Screw KA3.5x12
3 VF90201A 1 Safety Switch Cover Left
2 VV68303 4 Screw KT3.5x15
5 VF90288 5 Washer Φ3.6xφ8x0.5
6 VF90210 2 Switch Fix Frame
7 VV60153 3 Switch Rl2 P
9 VF90235 11 Screw Tm4x10
11 VF90285 1 Switch Seal Strip
12 VF90251 2 Safety Switch Connector Cable Kit
13 VF90250-1 1 20”Switch Connector Cable Kit
14 VF90238-3 1 Control Panel Connector Cable
15 VF90216 2 Switch Seal Bushing
16 VF90202 4 Spring
17 VF90252 2 Switch
18 VF90212A 1 Safety Switch Cover Right
19 VF90219 2 Gasket
20 VA13469 4 Screw M3x12
21 VF90213 2 Switch Seal Ring
22 VF90287 1 Hour Meter
23 VA14584 2 Screw PB3.0x8
24 VF90008-CL 1 20” Decal Control Panel
25 VF90245A 1 20” Switch Cover
26 VF90238-2 1 Led Indicator Battery Level
27 VF90207 2 Charger Fix Bracket
28 VF90227-US 1 Charger
29 VA80758 6 Screw Pa4x16
30 VF90211 1 Plug Fix
31 GT13092 2 Screw ST3.5x18
32 VF90249-1 1 20”Main Cable Kit
Item Ref. No. Qty Description
33 GT13091 9 SCREW PB3.5x8
34 VF90238-1 1 17” Control Circuit Board
35 VF90209 1 PCB Housing
36 VF90237 3 Nylon Cable Hook
37 VF90221 3 Nylon Cable
38 VF14514 7 Nut Lock M5
39 VF90259 1 Hand Fix Panel
40 ZD48320 2 Circuit Breaker
41 VF90020 1 Vacuum Circuit Label
42 80407A 2 Screw M5x25
43 VF90215 1 Power Safety Cover
44 VF90019 1 Brush Circuit Label
45 VF89076 2 Circuit Breaker Cap
46 VF90116 1 Hand Bracket
47 VF90243 2 Screw Pm4x8
48 VF90230 1 Electromagnetic Switch 24v Dc
49 VA13400 2 Washer Φ5x Φ12x1
50 VF85301 1 Cable Support
51 VF13533 2 Washer Φ6.2x Φ16x1
52 VA13474 2 Screw M5x16
53 VF90815A 1 Cover Control Housing
54 GT13054 4 Screw Tm5x12
55 1 20” Serial Number Label
56 GV70034 1 Clamp Drain Hose
57 VF14538 2 SCREW ST3.5x16
58 VF90004 1 Label Battery Level
59 VF90129 1 Screw M5x20
60 VF90113 1 Handle Lift
61 VF90128 2 Screw M5
62 VF90114 1 Cable Squeegee Lift
63 VA14584 2 SCREW PB3.0x8
To Next Page
