7/2014 D - 7 56091130 - CA30 20B
PARTS LIST
WHEELS AND SOLUTION SYSTEM
Item Ref. No. Qty Description
1 VF89203 2 Wheel Cover
2 VF14563 2 Leville Washer
3 VF14554 12 Washer
4 VF90304 1 Wheel Shaft
5 VF82172 1 Spring 70°
6 VF90305 2 8” Wheel
7 VF14552 2 Ring D 17
8 VF90282 1 Solenoid Valve Kit
9 VV10114 2 Clamp
10 VF90440 1 Tubing L=260mm
11 VF90604 1 Filter Base
12 VF90608 1 Filter Net
13 VF90607 1 O-Ring
14 VF90603 1 Filter Cover
15 VF90621 1 Filter Kit
16 VA13507 2 Screw St4x12
17 VF90441 1 Tubing L=160mm
18 VF90625 1 Solenoid Valve Bracket
19 VA13483 2 Washer Φ4*Φ12.5*1.5
20 VV13650A 2 Screw M4x10
21 VF82148 2 Clamp, Hose
22 VF80313 1 Barb, Hose
23 VF80361 1 Ball Valve
24 VF90609 1 Elbow,90º,Brass
To Next Page
