Clarke Fusion 20 Troubleshooting Guide

22
Fig 3- Pull down on the dust skirt to
gain access to the adjustment
hardware.
Pivot bolt
rear
Pivot bracket has slots to
allow adjustment.
Pivot bracket
Loosen pivot bracket
adjustment hardware and rotate
bracket counterclockwise to
increase pad assist.
Pivot bolt
front

Clarke Fusion 20 Specifications

General

Brand	Clarke
Model	Fusion 20
Category	Floor Machine
Language	English
