Clarke Fusion 20 Troubleshooting Guide

24
Fusion Burnisher Pad Motor Assembly Removal
Step 1
Step 2.
This would be the machine (Fusion 20B or 20T)
that you would remove the Pad Motor Assy. from.
The pictures shown in this instruction are using a
Fusion 20T. The Pad Motor Assy. removal and
reinstallation is the same for both burnishers.
Remove the top cover. Remove the electrical
access cover using the screw at the top of the
cover with an Allen wrench.
